The Gaudi Framework: AlgTool Class Reference

Definition: StatusCode.h:30

StatusCode AlgTool::configure ( )

inlineoverride

Definition at line 67 of file AlgTool.h.

67 { return StatusCode::SUCCESS; }

Definition: StatusCode.h:30

template<class T >

void AlgTool::declareInfo	(	const std::string &	name,
		const T &	var,
		const std::string &	desc
	)		const

inline

Declare monitoring information.

Parameters

name	Monitoring information name known to the external system
var	Monitoring Listener address (the item to monitor...)
desc	Textual description of the information being monitored

Definition at line 529 of file AlgTool.h.

   {
     IMonitorSvc* mS = monitorSvc();
     if ( mS ) mS->declareInfo(name, var, desc, this);
   }

template<class T >

void AlgTool::declareInfo	(	const std::string &	name,
		const T &	var,
		const std::string &	desc
	)		const

inline

Declare monitoring information.

Parameters

name	Monitoring information name known to the external system
var	Monitoring Listener address (the item to monitor...)
desc	Textual description of the information being monitored

Definition at line 529 of file AlgTool.h.

   {
     IMonitorSvc* mS = monitorSvc();
     if ( mS ) mS->declareInfo(name, var, desc, this);
   }

void AlgTool::declareInfo	(	const std::string &	name,
		const std::string &	format,
		const void *	var,
		int	size,
		const std::string &	desc
	)		const

inline

Declare monitoring information (special case)

Parameters

name	Monitoring information name known to the external system
format	Format information
var	Monitoring Listener address
size	Monitoring Listener address size
desc	Textual description of the information being monitored

Definition at line 544 of file AlgTool.h.

   {
     IMonitorSvc* mS = monitorSvc();
     if ( mS ) mS->declareInfo(name, format, var, size, desc, this);
   }

void AlgTool::declareInfo	(	const std::string &	name,
		const std::string &	format,
		const void *	var,
		int	size,
		const std::string &	desc
	)		const

inline

Declare monitoring information (special case)

Parameters

name	Monitoring information name known to the external system
format	Format information
var	Monitoring Listener address
size	Monitoring Listener address size
desc	Textual description of the information being monitored

Definition at line 544 of file AlgTool.h.

   {
     IMonitorSvc* mS = monitorSvc();
     if ( mS ) mS->declareInfo(name, format, var, size, desc, this);
   }

template<class T >

StatusCode AlgTool::declareInput	(	const std::string &	propertyName,
		DataObjectHandle< T > &	handle,
		const std::string &	address = `DataObjectDescriptor::NULL_`,
		bool	optional = `false`,
		MinimalDataObjectHandle::AccessType	accessType = `MinimalDataObjectHandle::READ`
	)

inline

Declare input data object.

Parameters

propertyName	to identify input object in python config
handle	data handle
address	relative or absolute address in TES
optional	optional input
accessType	read, write or update

Definition at line 274 of file AlgTool.h.

                                                  {

         bool res = m_inputDataObjects.insert(propertyName, &handle);

         handle.descriptor()->setTag(propertyName);
         handle.descriptor()->setAddress(address);
         handle.descriptor()->setAccessType(accessType);
         handle.descriptor()->setOptional(optional);

         handle.setOwner(this);

         MsgStream log(msgSvc(), name());

         if (LIKELY(res)) {
             log << MSG::DEBUG << "Handle for " << propertyName << " ("
                     << address << ")" << " successfully created and stored."
                     << endmsg;
         } else {
             log << MSG::ERROR << "Handle for " << propertyName << " ("
                     << address << ")" << " could not be created." << endmsg;
         }

         return res;

     }

template<class T >

StatusCode AlgTool::declareInput	(	const std::string &	propertyName,
		DataObjectHandle< T > &	handle,
		const std::string &	address = `DataObjectDescriptor::NULL_`,
		bool	optional = `false`,
		MinimalDataObjectHandle::AccessType	accessType = `MinimalDataObjectHandle::READ`
	)

inline

Declare input data object.

Parameters

propertyName	to identify input object in python config
handle	data handle
address	relative or absolute address in TES
optional	optional input
accessType	read, write or update

Definition at line 274 of file AlgTool.h.

                                                  {

         bool res = m_inputDataObjects.insert(propertyName, &handle);

         handle.descriptor()->setTag(propertyName);
         handle.descriptor()->setAddress(address);
         handle.descriptor()->setAccessType(accessType);
         handle.descriptor()->setOptional(optional);

         handle.setOwner(this);

         MsgStream log(msgSvc(), name());

         if (LIKELY(res)) {
             log << MSG::DEBUG << "Handle for " << propertyName << " ("
                     << address << ")" << " successfully created and stored."
                     << endmsg;
         } else {
             log << MSG::ERROR << "Handle for " << propertyName << " ("
                     << address << ")" << " could not be created." << endmsg;
         }

         return res;

     }

template<class T >

StatusCode AlgTool::declareInput	(	const std::string &	propertyName,
		DataObjectHandle< T > &	handle,
		const std::vector< std::string > &	addresses,
		bool	optional = `false`,
		MinimalDataObjectHandle::AccessType	accessType = `MinimalDataObjectHandle::READ`
	)

inline

Declare input data object.

Parameters

propertyName	to identify input object in python config
handle	data handle
addresses	relative or absolute addresses in TES, first is main address
optional	optional input
accessType	read, write or update

Definition at line 313 of file AlgTool.h.

                                                  {

         bool res = m_inputDataObjects.insert(propertyName, &handle);

         handle.descriptor()->setTag(propertyName);
         handle.descriptor()->setAddresses(addresses);
         handle.descriptor()->setAccessType(accessType);
         handle.descriptor()->setOptional(optional);

         handle.setOwner(this);

         MsgStream log(msgSvc(), name());

         if (LIKELY(res)) {
             log << MSG::DEBUG << "Handle for " << propertyName << " ("
                     << (addresses.empty() ? DataObjectDescriptor::NULL_ : addresses[0]) << ")" << " successfully created and stored."
                     << endmsg;
         } else {
             log << MSG::ERROR << "Handle for " << propertyName << " ("
                     << (addresses.empty() ? DataObjectDescriptor::NULL_ : addresses[0]) << ")" << " could not be created." << endmsg;
         }

         return res;

     }

template<class T >

StatusCode AlgTool::declareInput	(	const std::string &	propertyName,
		DataObjectHandle< T > &	handle,
		const std::vector< std::string > &	addresses,
		bool	optional = `false`,
		MinimalDataObjectHandle::AccessType	accessType = `MinimalDataObjectHandle::READ`
	)

inline

Declare input data object.

Parameters

propertyName	to identify input object in python config
handle	data handle
addresses	relative or absolute addresses in TES, first is main address
optional	optional input
accessType	read, write or update

Definition at line 313 of file AlgTool.h.

                                                  {

         bool res = m_inputDataObjects.insert(propertyName, &handle);

         handle.descriptor()->setTag(propertyName);
         handle.descriptor()->setAddresses(addresses);
         handle.descriptor()->setAccessType(accessType);
         handle.descriptor()->setOptional(optional);

         handle.setOwner(this);

         MsgStream log(msgSvc(), name());

         if (LIKELY(res)) {
             log << MSG::DEBUG << "Handle for " << propertyName << " ("
                     << (addresses.empty() ? DataObjectDescriptor::NULL_ : addresses[0]) << ")" << " successfully created and stored."
                     << endmsg;
         } else {
             log << MSG::ERROR << "Handle for " << propertyName << " ("
                     << (addresses.empty() ? DataObjectDescriptor::NULL_ : addresses[0]) << ")" << " could not be created." << endmsg;
         }

         return res;

     }

template<typename I >

void AlgTool::declareInterface ( I * i )

inlineprotected

Definition at line 215 of file AlgTool.h.

215 { m_interfaceList.emplace_back( I::interfaceID(), i ); }

AlgTool::m_interfaceList

InterfaceList m_interfaceList

Interface list.

Definition: AlgTool.h:585

ana.i

list i

Definition: ana.py:128

template<typename I >

void AlgTool::declareInterface ( I * i )

inlineprotected

Definition at line 215 of file AlgTool.h.

215 { m_interfaceList.emplace_back( I::interfaceID(), i ); }

AlgTool::m_interfaceList

InterfaceList m_interfaceList

Interface list.

Definition: AlgTool.h:585

ana.i

list i

Definition: ana.py:128

template<class T >

StatusCode AlgTool::declareOutput	(	const std::string &	propertyName,
		DataObjectHandle< T > &	handle,
		const std::string &	address = `DataObjectDescriptor::NULL_`,
		bool	optional = `false`,
		MinimalDataObjectHandle::AccessType	accessType = `MinimalDataObjectHandle::WRITE`
	)

inline

Declare output data object.

Parameters

propertyName	to identify input object in python config
handle	data handle
address	relative or absolute address in TES
optional	optional input
accessType	write or update

Definition at line 351 of file AlgTool.h.

                                                                                          {

         bool res = m_outputDataObjects.insert(propertyName, &handle);

         handle.descriptor()->setTag(propertyName);
         handle.descriptor()->setAddress(address);
         handle.descriptor()->setAccessType(accessType);
         handle.descriptor()->setOptional(optional);

         handle.setOwner(this);

         MsgStream log(msgSvc(), name());

         if (LIKELY(res)) {
             log << MSG::DEBUG << "Handle for " << propertyName << " ("
                     << address << ")" << " successfully created and stored."
                     << endmsg;
         } else {
             log << MSG::ERROR << "Handle for " << propertyName << " ("
                     << address << ")" << " could not be created." << endmsg;
         }

         return res;

     }

template<class T >

StatusCode AlgTool::declareOutput	(	const std::string &	propertyName,
		DataObjectHandle< T > &	handle,
		const std::string &	address = `DataObjectDescriptor::NULL_`,
		bool	optional = `false`,
		MinimalDataObjectHandle::AccessType	accessType = `MinimalDataObjectHandle::WRITE`
	)

inline

Declare output data object.

Parameters

propertyName	to identify input object in python config
handle	data handle
address	relative or absolute address in TES
optional	optional input
accessType	write or update

Definition at line 351 of file AlgTool.h.

                                                                                          {

         bool res = m_outputDataObjects.insert(propertyName, &handle);

         handle.descriptor()->setTag(propertyName);
         handle.descriptor()->setAddress(address);
         handle.descriptor()->setAccessType(accessType);
         handle.descriptor()->setOptional(optional);

         handle.setOwner(this);

         MsgStream log(msgSvc(), name());

         if (LIKELY(res)) {
             log << MSG::DEBUG << "Handle for " << propertyName << " ("
                     << address << ")" << " successfully created and stored."
                     << endmsg;
         } else {
             log << MSG::ERROR << "Handle for " << propertyName << " ("
                     << address << ")" << " could not be created." << endmsg;
         }

         return res;

     }

template<class T >

StatusCode AlgTool::declarePrivateTool	(	ToolHandle< T > &	handle,
		std::string	toolTypeAndName = `""`,
		bool	createIf = `true`
	)

inline

Declare used private tool.

Parameters

handle	ToolHandle<T>
toolTypeAndName
parent,default	public tool
create	if necessary, default true

Definition at line 459 of file AlgTool.h.

                                       {

         if (toolTypeAndName == "")
             toolTypeAndName = System::typeinfoName(typeid(T));

         StatusCode sc = handle.initialize(toolTypeAndName, this, createIf);

         m_toolHandles.push_back(&handle);

         MsgStream log(msgSvc(), name());

         if (sc.isSuccess()) {
             log << MSG::DEBUG << "Handle for private tool" << toolTypeAndName
                     << " successfully created and stored." << endmsg;
         } else {

             log << MSG::ERROR << "Handle for private tool" << toolTypeAndName
                     << " could not be created." << endmsg;
         }

         return sc;

     }

template<class T >

StatusCode AlgTool::declarePrivateTool	(	ToolHandle< T > &	handle,
		std::string	toolTypeAndName = `""`,
		bool	createIf = `true`
	)

inline

Declare used private tool.

Parameters

handle	ToolHandle<T>
toolTypeAndName
parent,default	public tool
create	if necessary, default true

Definition at line 459 of file AlgTool.h.

                                       {

         if (toolTypeAndName == "")
             toolTypeAndName = System::typeinfoName(typeid(T));

         StatusCode sc = handle.initialize(toolTypeAndName, this, createIf);

         m_toolHandles.push_back(&handle);

         MsgStream log(msgSvc(), name());

         if (sc.isSuccess()) {
             log << MSG::DEBUG << "Handle for private tool" << toolTypeAndName
                     << " successfully created and stored." << endmsg;
         } else {

             log << MSG::ERROR << "Handle for private tool" << toolTypeAndName
                     << " could not be created." << endmsg;
         }

         return sc;

     }

template<class T >

Property* AlgTool::declareProperty	(	const std::string &	name,
		T &	property,
		const std::string &	doc = `"none"`
	)		const

inline

Declare the named property.

MyTool ( const std::string& type   ,
         const std::string& name   ,
         const IInterface*  parent )
   : AlgTool  ( type , name , pSvc )
   , m_property1   ( ... )
   , m_property2   ( ... )
 {
   // declare the property
   declareProperty( "Property1" , m_property1 , "Doc for property #1" ) ;
   // declare the property and attach the handler to it
   declareProperty( "Property2" , m_property2 , "Doc for property #2" )
      -> declareUpdateHandler( &MyTool::handler_2 ) ;
 }

See also: PropertyMgr; PropertyMgr::declareProperty

Parameters

name	the property name
property	the property itself,
doc	the documentation string

Returns: the actual property objects

Definition at line 249 of file AlgTool.h.

   {
     return m_propertyMgr -> declareProperty ( name , property , doc ) ;
   }

template<class T >

Property* AlgTool::declareProperty	(	const std::string &	name,
		T &	property,
		const std::string &	doc = `"none"`
	)		const

inline

Declare the named property.

MyTool ( const std::string& type   ,
         const std::string& name   ,
         const IInterface*  parent )
   : AlgTool  ( type , name , pSvc )
   , m_property1   ( ... )
   , m_property2   ( ... )
 {
   // declare the property
   declareProperty( "Property1" , m_property1 , "Doc for property #1" ) ;
   // declare the property and attach the handler to it
   declareProperty( "Property2" , m_property2 , "Doc for property #2" )
      -> declareUpdateHandler( &MyTool::handler_2 ) ;
 }

See also: PropertyMgr; PropertyMgr::declareProperty

Parameters

name	the property name
property	the property itself,
doc	the documentation string

Returns: the actual property objects

Definition at line 249 of file AlgTool.h.

   {
     return m_propertyMgr -> declareProperty ( name , property , doc ) ;
   }

template<class T >

StatusCode AlgTool::declarePublicTool	(	ToolHandle< T > &	handle,
		std::string	toolTypeAndName = `""`,
		bool	createIf = `true`
	)

inline

Declare used public tool.

Parameters

handle	ToolHandle<T>
toolTypeAndName
parent,default	public tool
create	if necessary, default true

Definition at line 426 of file AlgTool.h.

                                       {

         if (toolTypeAndName == "")
             toolTypeAndName = System::typeinfoName(typeid(T));

         StatusCode sc = handle.initialize(toolTypeAndName, 0, createIf);

         m_toolHandles.push_back(&handle);

         MsgStream log(msgSvc(), name());

         if (sc.isSuccess()) {
             log << MSG::DEBUG << "Handle for public tool" << toolTypeAndName
                     << " successfully created and stored." << endmsg;
         } else {

             log << MSG::ERROR << "Handle for public tool" << toolTypeAndName
                     << " could not be created." << endmsg;
         }

         return sc;

     }

template<class T >

StatusCode AlgTool::declarePublicTool	(	ToolHandle< T > &	handle,
		std::string	toolTypeAndName = `""`,
		bool	createIf = `true`
	)

inline

Declare used public tool.

Parameters

handle	ToolHandle<T>
toolTypeAndName
parent,default	public tool
create	if necessary, default true

Definition at line 426 of file AlgTool.h.

                                       {

         if (toolTypeAndName == "")
             toolTypeAndName = System::typeinfoName(typeid(T));

         StatusCode sc = handle.initialize(toolTypeAndName, 0, createIf);

         m_toolHandles.push_back(&handle);

         MsgStream log(msgSvc(), name());

         if (sc.isSuccess()) {
             log << MSG::DEBUG << "Handle for public tool" << toolTypeAndName
                     << " successfully created and stored." << endmsg;
         } else {

             log << MSG::ERROR << "Handle for public tool" << toolTypeAndName
                     << " could not be created." << endmsg;
         }

         return sc;

     }

Property* AlgTool::declareRemoteProperty	(	const std::string &	name,
		IProperty *	rsvc,
		const std::string &	rname = `""`
	)		const

inline

Declare remote named properties.

Definition at line 257 of file AlgTool.h.

   {
     return m_propertyMgr-> declareRemoteProperty ( name , rsvc , rname ) ;
   }

Property* AlgTool::declareRemoteProperty	(	const std::string &	name,
		IProperty *	rsvc,
		const std::string &	rname = `""`
	)		const

inline

Declare remote named properties.

Definition at line 257 of file AlgTool.h.

   {
     return m_propertyMgr-> declareRemoteProperty ( name , rsvc , rname ) ;
   }

void AlgTool::deregisterTool ( IAlgTool * tool ) const

inline

Definition at line 403 of file AlgTool.h.

                                                {
         std::vector<IAlgTool *>::iterator it = std::find(m_tools.begin(),
                 m_tools.end(), tool);

         MsgStream log(msgSvc(), name());
         if (it != m_tools.end()) {
             log << MSG::DEBUG << "De-Registering tool " << tool->name()
                     << endmsg;
             m_tools.erase(it);
         } else {
             log << MSG::DEBUG << "Could not de-register tool " << tool->name()
                     << endmsg;
         }
     }

void AlgTool::deregisterTool ( IAlgTool * tool ) const

inline

Definition at line 403 of file AlgTool.h.

                                                {
         std::vector<IAlgTool *>::iterator it = std::find(m_tools.begin(),
                 m_tools.end(), tool);

         MsgStream log(msgSvc(), name());
         if (it != m_tools.end()) {
             log << MSG::DEBUG << "De-Registering tool " << tool->name()
                     << endmsg;
             m_tools.erase(it);
         } else {
             log << MSG::DEBUG << "Could not de-register tool " << tool->name()
                     << endmsg;
         }
     }

IDataProviderSvc * AlgTool::evtSvc ( ) const

accessor to event service service

Returns: pointer to detector service

Definition at line 101 of file AlgTool.cpp.

 {
   if ( !m_evtSvc ) {
     m_evtSvc = service("EventDataSvc", true);
     if ( !m_evtSvc ) {
       throw GaudiException("Service [EventDataSvc] not found", name(), StatusCode::FAILURE);
     }
   }
   return m_evtSvc.get();
 }

IDataProviderSvc* AlgTool::evtSvc ( ) const

accessor to event service service

Returns: pointer to detector service

StatusCode AlgTool::finalize ( )

override

Definition at line 395 of file AlgTool.cpp.

 {
   // For the time being there is nothing to be done here.
   return StatusCode::SUCCESS;
 }

StatusCode AlgTool::finalize ( )

override

Gaudi::StateMachine::State AlgTool::FSMState ( ) const

inlineoverride

Definition at line 75 of file AlgTool.h.

75 { return m_state; }

AlgTool::m_state

Gaudi::StateMachine::State m_state

state of the Tool

Definition: AlgTool.h:616

Gaudi::StateMachine::State AlgTool::FSMState ( ) const

inlineoverride

Definition at line 75 of file AlgTool.h.

75 { return m_state; }

AlgTool::m_state

Gaudi::StateMachine::State m_state

state of the Tool

Definition: AlgTool.h:616

const std::vector<Property*>& AlgTool::getProperties ( ) const

override

const std::vector< Property * > & AlgTool::getProperties ( ) const

override

Definition at line 166 of file AlgTool.cpp.

 {
   return m_propertyMgr->getProperties();
 }

StatusCode AlgTool::getProperty ( Property * p ) const

override

StatusCode AlgTool::getProperty ( Property * p ) const

override

Definition at line 146 of file AlgTool.cpp.

 {
   return m_propertyMgr->getProperty(p);
 }

const Property& AlgTool::getProperty ( const std::string & name ) const

override

const Property & AlgTool::getProperty ( const std::string & name ) const

override

Definition at line 153 of file AlgTool.cpp.

 {
   return m_propertyMgr->getProperty(n);
 }

StatusCode AlgTool::getProperty	(	const std::string &	n,
		std::string &	v
	)		const

override

StatusCode AlgTool::getProperty	(	const std::string &	n,
		std::string &	v
	)		const

override

Definition at line 159 of file AlgTool.cpp.

 {
   return m_propertyMgr->getProperty(n,v);
 }

PropertyMgr* AlgTool::getPropertyMgr ( )

inline

Definition at line 106 of file AlgTool.h.

106 { return m_propertyMgr.get(); }

TYPE * get() const

Get interface pointer.

Definition: SmartIF.h:76

SmartIF< PropertyMgr > m_propertyMgr

Property Manager.

Definition: AlgTool.h:584

PropertyMgr* AlgTool::getPropertyMgr ( )

inline

Definition at line 106 of file AlgTool.h.

106 { return m_propertyMgr.get(); }

TYPE * get() const

Get interface pointer.

Definition: SmartIF.h:76

SmartIF< PropertyMgr > m_propertyMgr

Property Manager.

Definition: AlgTool.h:584

bool AlgTool::hasProperty ( const std::string & name ) const

override

bool AlgTool::hasProperty ( const std::string & name ) const

override

Definition at line 172 of file AlgTool.cpp.

                                                      {
   return m_propertyMgr->hasProperty(name);
 }

StatusCode AlgTool::initialize ( )

override

StatusCode AlgTool::initialize ( )

override

Definition at line 325 of file AlgTool.cpp.

 {
   // For the time being there is nothing to be done here.
   // Setting the properties is done by the ToolSvc calling setProperties()
   // explicitly.
   return StatusCode::SUCCESS;
 }

void AlgTool::initOutputLevel ( Property & prop )

protected

callback for output level property

void AlgTool::initOutputLevel ( Property & prop )

protected

callback for output level property

Definition at line 577 of file AlgTool.cpp.

                                           {
 //-----------------------------------------------------------------------------
    // do nothing... yet ?
 }

void AlgTool::initToolHandles ( ) const

private

Definition at line 501 of file AlgTool.cpp.

                                    {

     MsgStream log ( msgSvc() , name() ) ;

     for(auto th : m_toolHandles){
         IAlgTool * tool = nullptr;

         //if(th->retrieve().isFailure())
             //log << MSG::DEBUG << "Error in retrieving tool from ToolHandle" << endmsg;

         //get generic tool interface from ToolHandle
         if(th->retrieve(tool).isSuccess() && tool != nullptr){
             m_tools.push_back(tool);
             log << MSG::DEBUG << "Adding ToolHandle tool " << tool->name() << " (" << tool->type() << ")" << endmsg;
         } else {
             log << MSG::DEBUG << "Trying to add nullptr tool" << endmsg;
         }
     }

     m_toolHandlesInit = true;
 }

void AlgTool::initToolHandles ( ) const

private

const DataObjectDescriptorCollection& AlgTool::inputDataObjects ( ) const

inlineoverride

get inputs

Returns: DataObjectDescriptorCollection of inputs

Definition at line 384 of file AlgTool.h.

                                                                              {
         return m_inputDataObjects;
     }

const DataObjectDescriptorCollection& AlgTool::inputDataObjects ( ) const

inlineoverride

get inputs

Returns: DataObjectDescriptorCollection of inputs

Definition at line 384 of file AlgTool.h.

                                                                              {
         return m_inputDataObjects;
     }

DataObjectDescriptorCollection& AlgTool::inputDataObjects ( )

inlineprotected

Definition at line 488 of file AlgTool.h.

                                                           {
           return m_inputDataObjects;
       }

DataObjectDescriptorCollection& AlgTool::inputDataObjects ( )

inlineprotected

Definition at line 488 of file AlgTool.h.

                                                           {
           return m_inputDataObjects;
       }

IMonitorSvc* AlgTool::monitorSvc ( ) const

inline

Access the monitor service.

Attention: Note that this method will return a NULL pointer if no monitor service is configured to be present. You must take this possibility into account when using the pointer

Returns: Pointer to the Monitor service

Return values

NULL	No monitor service is present
non-NULL	A monitor service is present and available to be used

Definition at line 516 of file AlgTool.h.

   {
     // If not already located try to locate it without forcing a creation
     if ( !m_pMonitorSvc ) m_pMonitorSvc = service(m_monitorSvcName, false, true);
     return m_pMonitorSvc.get();
   }

IMonitorSvc* AlgTool::monitorSvc ( ) const

inline

Access the monitor service.

Attention: Note that this method will return a NULL pointer if no monitor service is configured to be present. You must take this possibility into account when using the pointer

Returns: Pointer to the Monitor service

Return values

NULL	No monitor service is present
non-NULL	A monitor service is present and available to be used

Definition at line 516 of file AlgTool.h.

   {
     // If not already located try to locate it without forcing a creation
     if ( !m_pMonitorSvc ) m_pMonitorSvc = service(m_monitorSvcName, false, true);
     return m_pMonitorSvc.get();
   }

IMessageSvc * AlgTool::msgSvc ( ) const

Retrieve pointer to message service.

Definition at line 92 of file AlgTool.cpp.

 {
   return m_messageSvc;
 }

IMessageSvc* AlgTool::msgSvc ( ) const

Retrieve pointer to message service.

const std::string& AlgTool::name ( ) const

override

Retrieve full identifying name of the concrete tool object.

const std::string & AlgTool::name ( ) const

override

Retrieve full identifying name of the concrete tool object.

Definition at line 64 of file AlgTool.cpp.

 {
   return m_name;
 }

const DataObjectDescriptorCollection& AlgTool::outputDataObjects ( ) const

inlineoverride

get outputs

Returns: DataObjectDescriptorCollection of outputs

Definition at line 392 of file AlgTool.h.

                                                                               {
         return m_outputDataObjects;
     }

const DataObjectDescriptorCollection& AlgTool::outputDataObjects ( ) const

inlineoverride

get outputs

Returns: DataObjectDescriptorCollection of outputs

Definition at line 392 of file AlgTool.h.

                                                                               {
         return m_outputDataObjects;
     }

DataObjectDescriptorCollection& AlgTool::outputDataObjects ( )

inlineprotected

Definition at line 491 of file AlgTool.h.

                                                            {
           return m_outputDataObjects;
       }

DataObjectDescriptorCollection& AlgTool::outputDataObjects ( )

inlineprotected

Definition at line 491 of file AlgTool.h.

                                                            {
           return m_outputDataObjects;
       }

int AlgTool::outputLevel ( ) const

inlineprotected

get tool's output level

Definition at line 557 of file AlgTool.h.

557 { return (int)m_outputLevel ; }

IntegerProperty m_outputLevel

AlgTool output level.

Definition: AlgTool.h:574

int AlgTool::outputLevel ( ) const

inlineprotected

get tool's output level

Definition at line 557 of file AlgTool.h.

557 { return (int)m_outputLevel ; }

IntegerProperty m_outputLevel

AlgTool output level.

Definition: AlgTool.h:574

IntegerProperty& AlgTool::outputLevelProperty ( )

inlineprotected

Accessor for the Message level property.

Definition at line 560 of file AlgTool.h.

560 { return m_outputLevel; }

IntegerProperty m_outputLevel

AlgTool output level.

Definition: AlgTool.h:574

IntegerProperty& AlgTool::outputLevelProperty ( )

inlineprotected

Accessor for the Message level property.

Definition at line 560 of file AlgTool.h.

560 { return m_outputLevel; }

IntegerProperty m_outputLevel

AlgTool output level.

Definition: AlgTool.h:574

const IInterface* AlgTool::parent ( ) const

override

Retrieve parent of the sub-algtool.

const IInterface * AlgTool::parent ( ) const

override

Retrieve parent of the sub-algtool.

Definition at line 78 of file AlgTool.cpp.

 {
   return m_parent;
 }

StatusCode AlgTool::queryInterface	(	const InterfaceID &	riid,
		void **	ppvUnknown
	)

override

Query for a given interface.

StatusCode AlgTool::queryInterface	(	const InterfaceID &	riid,
		void **	ppvUnknown
	)

override

Query for a given interface.

Definition at line 44 of file AlgTool.cpp.

 {
   if ( !ppvi ) { return StatusCode::FAILURE ; } // RETURN
   StatusCode sc = base_class::queryInterface(riid,ppvi);
   if (sc.isSuccess()) return sc;
   auto i = std::find_if( std::begin(m_interfaceList), std::end(m_interfaceList),
                          [&](const std::pair<InterfaceID,void*>& item) {
                              return item.first.versionMatch(riid);
   } );
   if ( i == std::end(m_interfaceList) ) {
     *ppvi = nullptr ;
     return NO_INTERFACE ;  // RETURN
   }
   *ppvi = i->second ;
   addRef() ;
   return SUCCESS ;     // RETURN
 }

void AlgTool::registerTool ( IAlgTool * tool ) const

inline

Definition at line 396 of file AlgTool.h.

                                              {
         MsgStream log(msgSvc(), name());

         log << MSG::DEBUG << "Registering tool " << tool->name() << endmsg;
         m_tools.push_back(tool);
     }

void AlgTool::registerTool ( IAlgTool * tool ) const

inline

Definition at line 396 of file AlgTool.h.

                                              {
         MsgStream log(msgSvc(), name());

         log << MSG::DEBUG << "Registering tool " << tool->name() << endmsg;
         m_tools.push_back(tool);
     }

StatusCode AlgTool::reinitialize ( )

override

StatusCode AlgTool::reinitialize ( )

override

Definition at line 426 of file AlgTool.cpp.

 {
   /* @TODO
    * MCl 2008-10-23: the implementation of reinitialize as finalize+initialize
    *                 is causing too many problems
    *
   // Default implementation is finalize+initialize
   StatusCode sc = finalize();
   if (sc.isFailure()) {
     MsgStream log ( msgSvc(), name() );
     log << MSG::ERROR << "reinitialize(): cannot be finalized" << endmsg;
     return sc;
   }
   sc = initialize();
   if (sc.isFailure()) {
     MsgStream log ( msgSvc(), name() );
     log << MSG::ERROR << "reinitialize(): cannot be initialized" << endmsg;
     return sc;
   }
   */
   return StatusCode::SUCCESS;
 }

StatusCode AlgTool::restart ( )

override

StatusCode AlgTool::restart ( )

override

Definition at line 474 of file AlgTool.cpp.

 {
   // Default implementation is stop+start
   StatusCode sc = stop();
   if (sc.isFailure()) {
     MsgStream log ( msgSvc(), name() );
     log << MSG::ERROR << "restart(): cannot be stopped" << endmsg;
     return sc;
   }
   sc = start();
   if (sc.isFailure()) {
     MsgStream log ( msgSvc(), name() );
     log << MSG::ERROR << "restart(): cannot be started" << endmsg;
     return sc;
   }
   return StatusCode::SUCCESS;
 }

template<class T >

StatusCode AlgTool::service	(	const std::string &	name,
		T *&	svc,
		bool	createIf = `true`
	)		const

inline

Access a service by name, creating it if it doesn't already exist.

Definition at line 195 of file AlgTool.h.

                                                                  {
     return service_i(name, createIf, T::interfaceID(), (void**)&svc);
   }

template<class T >

StatusCode AlgTool::service	(	const std::string &	name,
		T *&	svc,
		bool	createIf = `true`
	)		const

inline

Access a service by name, creating it if it doesn't already exist.

Definition at line 195 of file AlgTool.h.

                                                                  {
     return service_i(name, createIf, T::interfaceID(), (void**)&svc);
   }

template<class T >

StatusCode AlgTool::service	(	const std::string &	type,
		const std::string &	name,
		T *&	svc
	)		const

inline

Access a service by name, type creating it if it doesn't already exist.

Definition at line 202 of file AlgTool.h.

                                                                                    {
     return service_i(type, name, T::interfaceID(), (void**)&svc);
   }

template<class T >

StatusCode AlgTool::service	(	const std::string &	type,
		const std::string &	name,
		T *&	svc
	)		const

inline

Access a service by name, type creating it if it doesn't already exist.

Definition at line 202 of file AlgTool.h.

                                                                                    {
     return service_i(type, name, T::interfaceID(), (void**)&svc);
   }

SmartIF<IService> AlgTool::service	(	const std::string &	name,
		const bool	createIf = `true`,
		const bool	quiet = `false`
	)		const

Return a pointer to the service identified by name (or "type/name")

SmartIF< IService > AlgTool::service	(	const std::string &	name,
		const bool	createIf = `true`,
		const bool	quiet = `false`
	)		const

Return a pointer to the service identified by name (or "type/name")

Definition at line 558 of file AlgTool.cpp.

                                                                                                      {
   const ServiceLocatorHelper helper(*serviceLocator(), *this);
   return helper.service(name, quiet, createIf);
 }

template<typename T >

SmartIF<T> AlgTool::service	(	const std::string &	name,
		const bool	createIf = `true`,
		const bool	quiet = `false`
	)		const

inline

Definition at line 210 of file AlgTool.h.

211 { return SmartIF<T>( service(name,createIf,quiet) ); }

SmartIF

Small smart pointer class with automatic reference counting for IInterface.

Definition: IConverter.h:14

AlgTool::service

StatusCode service(const std::string &name, T *&svc, bool createIf=true) const

Access a service by name, creating it if it doesn't already exist.

Definition: AlgTool.h:195

const std::string & name() const override

Retrieve full identifying name of the concrete tool object.

Definition: AlgTool.cpp:64

template<typename T >

SmartIF<T> AlgTool::service	(	const std::string &	name,
		const bool	createIf = `true`,
		const bool	quiet = `false`
	)		const

inline

Definition at line 210 of file AlgTool.h.

211 { return SmartIF<T>( service(name,createIf,quiet) ); }

SmartIF

Small smart pointer class with automatic reference counting for IInterface.

Definition: IConverter.h:14

AlgTool::service

StatusCode service(const std::string &name, T *&svc, bool createIf=true) const

Access a service by name, creating it if it doesn't already exist.

Definition: AlgTool.h:195

Gaudi::Utils::setProperty

const std::string & name() const override

Retrieve full identifying name of the concrete tool object.

Definition: AlgTool.cpp:64

StatusCode AlgTool::service_i	(	const std::string &	algName,
		bool	createIf,
		const InterfaceID &	iid,
		void **	ppSvc
	)		const

private

flag indicating whether ToolHandle tools have been added to m_tools

implementation of service method

StatusCode AlgTool::service_i	(	const std::string &	algName,
		bool	createIf,
		const InterfaceID &	iid,
		void **	ppSvc
	)		const

private

flag indicating whether ToolHandle tools have been added to m_tools

implementation of service method

Definition at line 540 of file AlgTool.cpp.

                                        {
   const ServiceLocatorHelper helper(*serviceLocator(), *this);
   return helper.getService(svcName, createIf, iid, ppSvc);
 }

StatusCode AlgTool::service_i	(	const std::string &	svcType,
		const std::string &	svcName,
		const InterfaceID &	iid,
		void **	ppS
	)		const

private

Definition at line 550 of file AlgTool.cpp.

                                        {
   const ServiceLocatorHelper helper(*serviceLocator(), *this);
   return  helper.createService(svcType, svcName, iid, ppSvc);
 }

StatusCode AlgTool::service_i	(	const std::string &	svcType,
		const std::string &	svcName,
		const InterfaceID &	iid,
		void **	ppS
	)		const

private

ISvcLocator* AlgTool::serviceLocator ( ) const

Retrieve pointer to service locator.

ISvcLocator * AlgTool::serviceLocator ( ) const

Retrieve pointer to service locator.

Definition at line 85 of file AlgTool.cpp.

 {
   return m_svcLocator;
 }

StatusCode AlgTool::setProperties ( )

Method for setting declared properties to the values specified in the jobOptions via the job option service.

This method is called by the ToolSvc after creating the concrete tool, before passing it to the requesting parent and does not need to be called explicitly.

Definition at line 177 of file AlgTool.cpp.

 {
   if( !m_svcLocator ) return StatusCode::FAILURE;
   auto jos = m_svcLocator->service<IJobOptionsSvc>("JobOptionsSvc");
   if( !jos )  return StatusCode::FAILURE;

   // set first generic Properties
   StatusCode sc = jos->setMyProperties( getGaudiThreadGenericName(name()), this );
   if( sc.isFailure() ) return StatusCode::FAILURE;

   // set specific Properties
   if (isGaudiThreaded(name())) {
     if(jos->setMyProperties( name(), this ).isFailure()) {
       return StatusCode::FAILURE;
     }
   }

   // Change my own outputlevel
   if ( m_messageSvc ) {
     if ( MSG::NIL != m_outputLevel )
     { m_messageSvc -> setOutputLevel ( name (), m_outputLevel ) ; }
     m_outputLevel = m_messageSvc -> outputLevel ( name () ) ;
   }
   return StatusCode::SUCCESS;
 }

StatusCode AlgTool::setProperties ( )

Method for setting declared properties to the values specified in the jobOptions via the job option service.

This method is called by the ToolSvc after creating the concrete tool, before passing it to the requesting parent and does not need to be called explicitly.

StatusCode AlgTool::setProperty ( const Property & p )

override

Default implementations for IProperty interface.

Definition at line 125 of file AlgTool.cpp.

 {
   return m_propertyMgr->setProperty(p);
 }

StatusCode AlgTool::setProperty ( const Property & p )

override

Default implementations for IProperty interface.

StatusCode AlgTool::setProperty ( const std::string & s )

override

Definition at line 132 of file AlgTool.cpp.

 {
   return m_propertyMgr->setProperty(s);
 }

StatusCode AlgTool::setProperty ( const std::string & s )

override

StatusCode AlgTool::setProperty	(	const std::string &	n,
		const std::string &	v
	)

override

StatusCode AlgTool::setProperty	(	const std::string &	n,
		const std::string &	v
	)

override

Definition at line 139 of file AlgTool.cpp.

 {
   return m_propertyMgr->setProperty(n,v);
 }

template<class TYPE >

StatusCode AlgTool::setProperty	(	const std::string &	name,
		const TYPE &	value
	)

inline

set the property form the value

std::vector<double> data = ... ;
setProperty( "Data" , data ) ;
std::map<std::string,double> cuts = ... ;
setProperty( "Cuts" , cuts ) ;
std::map<std::string,std::string> dict = ... ;
setProperty( "Dictionary" , dict ) ;

Note: the interface IProperty allows setting of the properties either directly from other properties or from strings only

This is very convenient in resetting of the default properties in the derived classes. E.g. without this method one needs to convert everything into strings to use IProperty::setProperty

setProperty ( "OutputLevel" , "1"    ) ;
setProperty ( "Enable"      , "True" ) ;
setProperty ( "ErrorMax"    , "10"   ) ;

For simple cases it is more or less ok, but for complicated properties it is just ugly..

Parameters

name	name of the property
value	value of the property

See also: Gaudi::Utils::setProperty

Author: Vanya BELYAEV ibely.nosp@m.aev@.nosp@m.physi.nosp@m.cs.s.nosp@m.yr.ed.nosp@m.u

Date: 2007-05-13

Definition at line 152 of file AlgTool.h.

154 { return Gaudi::Utils::setProperty ( m_propertyMgr.get() , name , value ) ; }

StatusCode setProperty(IProperty *component, const std::string &name, const TYPE &value, const std::string &doc)

simple function to set the property of the given object from the value

Definition: Property.h:1187

TYPE * get() const

Get interface pointer.

Definition: SmartIF.h:76

dump_component_properties.value

SmartIF< PropertyMgr > m_propertyMgr

Property Manager.

Definition: AlgTool.h:584

list value

Definition: dump_component_properties.py:12

Gaudi::Utils::setProperty

const std::string & name() const override

Retrieve full identifying name of the concrete tool object.

Definition: AlgTool.cpp:64

template<class TYPE >

StatusCode AlgTool::setProperty	(	const std::string &	name,
		const TYPE &	value
	)

inline

set the property form the value

std::vector<double> data = ... ;
setProperty( "Data" , data ) ;
std::map<std::string,double> cuts = ... ;
setProperty( "Cuts" , cuts ) ;
std::map<std::string,std::string> dict = ... ;
setProperty( "Dictionary" , dict ) ;

Note: the interface IProperty allows setting of the properties either directly from other properties or from strings only

This is very convenient in resetting of the default properties in the derived classes. E.g. without this method one needs to convert everything into strings to use IProperty::setProperty

setProperty ( "OutputLevel" , "1"    ) ;
setProperty ( "Enable"      , "True" ) ;
setProperty ( "ErrorMax"    , "10"   ) ;

For simple cases it is more or less ok, but for complicated properties it is just ugly..

Parameters

name	name of the property
value	value of the property

See also: Gaudi::Utils::setProperty

Author: Vanya BELYAEV ibely.nosp@m.aev@.nosp@m.physi.nosp@m.cs.s.nosp@m.yr.ed.nosp@m.u

Date: 2007-05-13

Definition at line 152 of file AlgTool.h.

154 { return Gaudi::Utils::setProperty ( m_propertyMgr.get() , name , value ) ; }

StatusCode setProperty(IProperty *component, const std::string &name, const TYPE &value, const std::string &doc)

simple function to set the property of the given object from the value

Definition: Property.h:1187

TYPE * get() const

Get interface pointer.

Definition: SmartIF.h:76

dump_component_properties.value

SmartIF< PropertyMgr > m_propertyMgr

Property Manager.

Definition: AlgTool.h:584

list value

Definition: dump_component_properties.py:12

const std::string & name() const override

Retrieve full identifying name of the concrete tool object.

Definition: AlgTool.cpp:64

StatusCode AlgTool::start ( )

override

StatusCode AlgTool::start ( )

override

Definition at line 350 of file AlgTool.cpp.

 {
   // For the time being there is nothing to be done here.
   return StatusCode::SUCCESS;
 }

StatusCode AlgTool::stop ( )

override

StatusCode AlgTool::stop ( )

override

Definition at line 373 of file AlgTool.cpp.

 {
   // For the time being there is nothing to be done here.
   return StatusCode::SUCCESS;
 }

ISvcLocator* AlgTool::svcLoc ( ) const

inline

shortcut for the method service locator

Definition at line 170 of file AlgTool.h.

170 { return serviceLocator() ; }

AlgTool::serviceLocator

ISvcLocator * serviceLocator() const

Retrieve pointer to service locator.

Definition: AlgTool.cpp:85

ISvcLocator* AlgTool::svcLoc ( ) const

inline

shortcut for the method service locator

Definition at line 170 of file AlgTool.h.

170 { return serviceLocator() ; }

AlgTool::serviceLocator

ISvcLocator * serviceLocator() const

Retrieve pointer to service locator.

Definition: AlgTool.cpp:85

StatusCode AlgTool::sysFinalize ( )

override

Finalize AlgTool.

StatusCode AlgTool::sysFinalize ( )

override

Finalize AlgTool.

Definition at line 381 of file AlgTool.cpp.

                                 {
 //-----------------------------------------------------------------------------
   return attempt( *this, "sysFinalize", [&]() {
     m_targetState = Gaudi::StateMachine::ChangeState( Gaudi::StateMachine::FINALIZE, m_state);
     Gaudi::Guards::AuditorGuard guard(this,
                                       // check if we want to audit the initialize
                                       m_auditorFinalize ? auditorSvc() : nullptr,
                                       IAuditor::Finalize);
     StatusCode sc = finalize();
     if (sc.isSuccess()) m_state = m_targetState;
     return sc;
   } );
 }

StatusCode AlgTool::sysInitialize ( )

override

Initialize AlgTool.

StatusCode AlgTool::sysInitialize ( )

override

Initialize AlgTool.

Definition at line 282 of file AlgTool.cpp.

                                   {
 //-----------------------------------------------------------------------------
   return attempt( *this, "sysInitialize", [&]() {
     m_targetState = Gaudi::StateMachine::ChangeState( Gaudi::StateMachine::INITIALIZE, m_state);
     Gaudi::Guards::AuditorGuard guard(this,
                                       // check if we want to audit the initialize
                                       m_auditorInitialize ? auditorSvc() : nullptr,
                                       IAuditor::Initialize);
     StatusCode sc = initialize();
     if (sc.isSuccess()) m_state = m_targetState;

     // update DataHandles to point to full TES location
     // init data handle
     MsgStream log(msgSvc(), name());
     for (auto tag : m_inputDataObjects) {
       if (m_inputDataObjects[tag].isValid()) {
         if (m_inputDataObjects[tag].initialize().isSuccess())
           log << MSG::DEBUG << "Data Handle " << tag << " ("
           << m_inputDataObjects[tag].dataProductName()
           << ") initialized" << endmsg;
         else
           log << MSG::FATAL << "Data Handle " << tag << " ("
           << m_inputDataObjects[tag].dataProductName()
           << ") could NOT be initialized" << endmsg;
       }
     }
     for (auto tag : m_outputDataObjects) {
       if (m_outputDataObjects[tag].isValid()) {
         if (m_outputDataObjects[tag].initialize().isSuccess())
           log << MSG::DEBUG << "Data Handle " << tag << " ("
           << m_outputDataObjects[tag].dataProductName()
           << ") initialized" << endmsg;
         else
           log << MSG::FATAL << "Data Handle " << tag << " ("
           << m_outputDataObjects[tag].dataProductName()
           << ") could NOT be initialized" << endmsg;
       }
     }

     return sc;
   } );
 }

StatusCode AlgTool::sysReinitialize ( )

override

Initialize AlgTool.

StatusCode AlgTool::sysReinitialize ( )

override

Initialize AlgTool.

Definition at line 403 of file AlgTool.cpp.

                                     {
 //-----------------------------------------------------------------------------

   // Check that the current status is the correct one.
   if ( Gaudi::StateMachine::INITIALIZED != FSMState() ) {
     MsgStream log ( msgSvc(), name() );
     log << MSG::ERROR
         << "sysReinitialize(): cannot reinitialize tool not initialized"
         << endmsg;
     return StatusCode::FAILURE;
   }

   return attempt(*this, "SysReinitialize()", [&]() {
     Gaudi::Guards::AuditorGuard guard(this,
                                       // check if we want to audit the initialize
                                       m_auditorReinitialize ? auditorSvc() : nullptr,
                                       IAuditor::ReInitialize);
     return reinitialize();
   } );

 }

StatusCode AlgTool::sysRestart ( )

override

Start AlgTool.

StatusCode AlgTool::sysRestart ( )

override

Start AlgTool.

Definition at line 451 of file AlgTool.cpp.

                                {
 //-----------------------------------------------------------------------------

   // Check that the current status is the correct one.
   if ( Gaudi::StateMachine::RUNNING != FSMState() ) {
     MsgStream log ( msgSvc(), name() );
     log << MSG::ERROR
         << "sysRestart(): cannot reinitialize tool not started"
         << endmsg;
     return StatusCode::FAILURE;
   }

   return attempt(*this, "sysRestart", [&]()  {
     m_targetState = Gaudi::StateMachine::ChangeState(Gaudi::StateMachine::START,m_state);
     Gaudi::Guards::AuditorGuard guard(this,
                                       // check if we want to audit the initialize
                                       m_auditorRestart ? auditorSvc() : nullptr,
                                       IAuditor::ReStart);
     return restart();
   } );
 }

StatusCode AlgTool::sysStart ( )

override

Start AlgTool.

Definition at line 335 of file AlgTool.cpp.

                              {
 //-----------------------------------------------------------------------------
   return attempt( *this, "sysInitialize", [&]() {
     m_targetState = Gaudi::StateMachine::ChangeState( Gaudi::StateMachine::START, m_state);
     Gaudi::Guards::AuditorGuard guard(this,
                                       // check if we want to audit the initialize
                                       m_auditorStart ? auditorSvc() : nullptr,
                                       IAuditor::Start);
     StatusCode sc = start();
     if (sc.isSuccess()) m_state = m_targetState;
     return sc;
   } );
 }

StatusCode AlgTool::sysStart ( )

override

Start AlgTool.

StatusCode AlgTool::sysStop ( )

override

Stop AlgTool.

Definition at line 358 of file AlgTool.cpp.

                             {
 //-----------------------------------------------------------------------------
   return attempt( *this, "sysStop", [&]() {
     m_targetState = Gaudi::StateMachine::ChangeState( Gaudi::StateMachine::STOP, m_state);
     Gaudi::Guards::AuditorGuard guard(this,
                                       // check if we want to audit the initialize
                                       m_auditorStop ? auditorSvc() : nullptr,
                                       IAuditor::Stop);
     StatusCode sc = stop();
     if (sc.isSuccess()) m_state = m_targetState;
     return sc;
   } );
 }

StatusCode AlgTool::sysStop ( )

override

Stop AlgTool.

Gaudi::StateMachine::State AlgTool::targetFSMState ( ) const

inlineoverride

Definition at line 76 of file AlgTool.h.

76 { return m_targetState; }

AlgTool::m_targetState

Gaudi::StateMachine::State m_targetState

state of the Tool

Definition: AlgTool.h:617

Gaudi::StateMachine::State AlgTool::targetFSMState ( ) const

inlineoverride

Definition at line 76 of file AlgTool.h.

76 { return m_targetState; }

AlgTool::m_targetState

Gaudi::StateMachine::State m_targetState

state of the Tool

Definition: AlgTool.h:617

StatusCode AlgTool::terminate ( )

inlineoverride

Definition at line 72 of file AlgTool.h.

72 { return StatusCode::SUCCESS; }

Definition: StatusCode.h:30

StatusCode AlgTool::terminate ( )

inlineoverride

Definition at line 72 of file AlgTool.h.

72 { return StatusCode::SUCCESS; }
