#include <RndmGenerators.h>
Inheritance diagram for Rndm::DefinedPdf:
The probability distribution function (Pdf) must be provided by the user as an array of positive real number. The array size must also be provided. The Pdf doesn't need to be normalized to 1. if IntType = 0 ( default value ) a uniform random number is generated. The uniform number is then transformed to the user's distribution using the cumulative probability distribution constructed from his histogram. The cumulative distribution is inverted using a binary search for the nearest bin boundary and a linear interpolation within the bin. Therefore a constant density within each bin is generated. if IntType = 1 no interpolation is performed and the result is a discrete distribution.
Definition at line 320 of file RndmGenerators.h.
Public Member Functions | |
| DefinedPdf (const std::vector< double > &pdf, long intpol) | |
| Standard Constructor. | |
| virtual | ~DefinedPdf () |
| Standard Destructor. | |
| std::vector< double > & | pdf () |
| Access pdf. | |
| long | interpolation () const |
| Access interpolation type. | |
| virtual IRndmGen::Param * | clone () const |
| Clone parameters. | |
Static Public Member Functions | |
| static const InterfaceID & | typeID () |
| Identifier for factory. | |
Protected Attributes | |
| std::vector< double > | m_pdf |
| Vector containing probability distribution function. | |
| long | m_interpolation |
| Interpolation type. | |
| Rndm::DefinedPdf::DefinedPdf | ( | const std::vector< double > & | pdf, | |
| long | intpol | |||
| ) | [inline] |
Standard Constructor.
Definition at line 328 of file RndmGenerators.h.
Referenced by clone().
00329 : IRndmGen::Param(IID_IRndmDefinedPdf), 00330 m_pdf(pdf), 00331 m_interpolation(intpol) { }
| virtual Rndm::DefinedPdf::~DefinedPdf | ( | ) | [inline, virtual] |
| std::vector<double>& Rndm::DefinedPdf::pdf | ( | ) | [inline] |
Access pdf.
Definition at line 335 of file RndmGenerators.h.
References m_pdf.
00335 { return m_pdf; }
| long Rndm::DefinedPdf::interpolation | ( | ) | const [inline] |
Access interpolation type.
Definition at line 337 of file RndmGenerators.h.
References m_interpolation.
00337 { return m_interpolation; }
| static const InterfaceID& Rndm::DefinedPdf::typeID | ( | ) | [inline, static] |
Identifier for factory.
Definition at line 339 of file RndmGenerators.h.
References IID_IRndmDefinedPdf.
00339 { return IID_IRndmDefinedPdf; }
| virtual IRndmGen::Param* Rndm::DefinedPdf::clone | ( | ) | const [inline, virtual] |
Clone parameters.
Implements IRndmGen::Param.
Definition at line 341 of file RndmGenerators.h.
References DefinedPdf(), m_interpolation, and m_pdf.
00341 { 00342 return new DefinedPdf(m_pdf,m_interpolation); 00343 }
std::vector<double> Rndm::DefinedPdf::m_pdf [protected] |
Vector containing probability distribution function.
Definition at line 323 of file RndmGenerators.h.
long Rndm::DefinedPdf::m_interpolation [protected] |
Interpolation type.
Definition at line 325 of file RndmGenerators.h.
Referenced by clone(), and interpolation().
