IInterface.h File Reference

#include "GaudiKernel/Kernel.h"
#include "GaudiKernel/System.h"
#include "GaudiKernel/StatusCode.h"
#include <ostream>
#include <boost/mpl/set.hpp>
#include <boost/mpl/insert.hpp>
#include <boost/mpl/fold.hpp>
#include <boost/mpl/for_each.hpp>
#include <typeinfo>
#include "GaudiKernel/extend_interfaces.h"
#include "GaudiKernel/implements.h"
#include "GaudiKernel/extends.h"

Include dependency graph for IInterface.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
class	InterfaceID
	Interface ID class. More...
class	Gaudi::InterfaceId< INTERFACE, majVers, minVers >
	Class to handle automatically the versioning of the interfaces when they are inheriting from other interfaces. More...
class	IInterface
	Definition of the basic interface. More...

Namespaces
namespace	Gaudi
	: AIDA interfaces visibility

Macros
#define	DeclareInterfaceID(name, major, minor)
	Macro to declare the interface ID when using the new mechanism of extending and implementing interfaces.
#define	DeclareInterfaceIDMultiBase(name, major, minor)
	Macro to declare the interface ID when using the new mechanism of extending and implementing interfaces.

Functions
template<typename TARGET >
TARGET *	Gaudi::Cast (IInterface *i)
	Cast a IInterface pointer to an IInterface specialization (TARGET).
template<typename TARGET >
const TARGET *	Gaudi::Cast (const IInterface *i)
	Cast a IInterface pointer to an IInterface specialization (TARGET).
template<class I >
bool	isValidInterface (I *i)
	Templated function that throws an exception if the version if the interface implemented by the object behind the interface is incompatible.
std::ostream &	operator<< (std::ostream &s, const InterfaceID &id)
	ostream operator for InterfaceID. Needed by PluginSvc
template<class DEST , class SRC >
DEST **	pp_cast (SRC **ptr)
	Small function to be used instead of the construct (void**)&pointer, which produces, on gcc 4.1 optimized, the warning warning: dereferencing type-punned pointer will break strict-aliasing rules The assempler code produced is equivalent to the one with the direct cast.

Macro Definition Documentation

#define DeclareInterfaceID	(		name,
			major,
			minor
	)

Value:

static const InterfaceID &interfaceID(){ return iid::interfaceID(); } \
  typedef Gaudi::InterfaceId< name , major , minor > iid; \
  typedef iid::iids::type ext_iids

Macro to declare the interface ID when using the new mechanism of extending and implementing interfaces.

Definition at line 23 of file IInterface.h.

#define DeclareInterfaceIDMultiBase	(		name,
			major,
			minor
	)

Value:

static const InterfaceID &interfaceID(){ return iid::interfaceID(); } \
  typedef Gaudi::InterfaceId< name , major , minor > iid

Macro to declare the interface ID when using the new mechanism of extending and implementing interfaces.

Definition at line 35 of file IInterface.h.

Function Documentation

template<class I >

bool isValidInterface

(

I *

i

)

Templated function that throws an exception if the version if the interface implemented by the object behind the interface is incompatible.

This is the case if the major version differs or that the minor version of the client is bigger than of the implementer.

Note

A call to this function implies an increment of the reference count in case of success.

Author

Pere Mato

Definition at line 257 of file IInterface.h.

                             {
  void* ii;
  StatusCode sc =  i->queryInterface( I::interfaceID(), &ii);
  return sc.isSuccess();
}

std::ostream& operator<< ( std::ostream &  s, const InterfaceID &  id  )

inline

ostream operator for InterfaceID. Needed by PluginSvc

Definition at line 265 of file IInterface.h.

                                                                       {
    s << "IID_" << id.id();
    return s;
}

template<class DEST , class SRC >

DEST** pp_cast ( SRC **  ptr )

inline

Small function to be used instead of the construct (void**)&pointer, which produces, on gcc 4.1 optimized, the warning warning: dereferencing type-punned pointer will break strict-aliasing rules The assempler code produced is equivalent to the one with the direct cast.

The function can be used als to replace the construct (IInterface *&)m_MySvc. Replacement rules:

(void**)&pointer	pp_cast<void>(&pointer)
(IInterface *&)m_mySvc	*pp_cast<IInterface>(&m_mySvc)

Definition at line 282 of file IInterface.h.

                                {
  return reinterpret_cast<DEST**>(ptr);
}
