(it->second)["Total Cycles"] = (it->second)["CPU_CLK_UNHALTED:THREAD_P"];
(it->second)[
"L2 Hit Impact"] = (it->second)[
"MEM_LOAD_RETIRED:L2_HIT"] *
I7_L2_HIT_CYCLES;
if((it->second)["MEM_LOAD_RETIRED:OTHER_CORE_L2_HIT_HITM"]>(it->second)["MEM_UNCORE_RETIRED:OTHER_CORE_L2_HITM"])
{
(it->second)[
"L2 Other Core Hit Impact"] = ((it->second)[
"MEM_LOAD_RETIRED:OTHER_CORE_L2_HIT_HITM"] - (it->second)[
"MEM_UNCORE_RETIRED:OTHER_CORE_L2_HITM"])*
I7_OTHER_CORE_L2_HIT_CYCLES;
}
else
{
(it->second)["L2 Other Core Hit Impact"] = 0.0;
}
(it->second)["L3 Miss -> Total Impact"] = (it->second)["L3 Miss -> Local DRAM Hit Impact"] + (it->second)["L3 Miss -> Remote DRAM Hit Impact"] + (it->second)["L3 Miss -> Remote Cache Hit Impact"];
(it->second)["Counted Stalled Cycles due to Load Ops"] = (it->second)["L3 Miss -> Total Impact"] + (it->second)["L2 Hit Impact"] + (it->second)["L1 DTLB Miss Impact"] + (it->second)["L3 Unshared Hit Impact"] + (it->second)["L2 Other Core Hit Modified Impact"] + (it->second)["L2 Other Core Hit Impact"];
(it->second)["Cycles spent during DIV & SQRT Ops"] = (it->second)["ARITH:CYCLES_DIV_BUSY"];
(it->second)["Total Counted Stalled Cycles"] = (it->second)["Counted Stalled Cycles due to Load Ops"] + (it->second)["Cycles spent during DIV & SQRT Ops"];
(it->second)["Stalled Cycles"] = (it->second)["Total Counted Stalled Cycles"];
(it->second)["% of Total Cycles"] = (it->second)["Stalled Cycles"] * 100 / (it->second)["CPU_CLK_UNHALTED:THREAD_P"];
(it->second)["L3 Miss % of Load Stalls"] = (it->second)["L3 Miss -> Total Impact"] * 100 / (it->second)["Counted Stalled Cycles due to Load Ops"];
(it->second)["L2 Hit % of Load Stalls"] = (it->second)["L2 Hit Impact"] * 100 / (it->second)["Counted Stalled Cycles due to Load Ops"];
(it->second)["L1 DTLB Miss % of Load Stalls"] = (it->second)["L1 DTLB Miss Impact"] * 100 / (it->second)["Counted Stalled Cycles due to Load Ops"];
(it->second)["L3 Unshared Hit % of Load Stalls"] = (it->second)["L3 Unshared Hit Impact"] * 100 / (it->second)["Counted Stalled Cycles due to Load Ops"];
(it->second)["L2 Other Core Hit % of Load Stalls"] = (it->second)["L2 Other Core Hit Impact"] * 100 / (it->second)["Counted Stalled Cycles due to Load Ops"];
(it->second)["L2 Other Core Hit Modified % of Load Stalls"] = (it->second)["L2 Other Core Hit Modified Impact"] * 100 / (it->second)["Counted Stalled Cycles due to Load Ops"];
(it->second)["DIV & SQRT Ops % of counted Stalled Cycles"] = (it->second)["Cycles spent during DIV & SQRT Ops"] * 100 / (it->second)["Total Counted Stalled Cycles"];
(it->second)[
"Cycles IFETCH served by L3 (Modified)"] = (it->second)[
"OFFCORE_RESPONSE_0:DMND_IFETCH:OTHER_CORE_HITM"] *
I7_IFETCH_L2_MISS_L3_HITM;
(it->second)[
"Cycles IFETCH served by L3 (Clean Snoop)"] = (it->second)[
"OFFCORE_RESPONSE_0:DMND_IFETCH:OTHER_CORE_HIT_SNP"] *
I7_IFETCH_L2_MISS_L3_HIT_SNOOP;
(it->second)["Total L2 IFETCH miss Impact"] = (it->second)["Cycles IFETCH served by Local DRAM"] + (it->second)["Cycles IFETCH served by L3 (Modified)"] + (it->second)["Cycles IFETCH served by L3 (Clean Snoop)"] + (it->second)["Cycles IFETCH served by Remote L2"] + (it->second)["Cycles IFETCH served by Remote DRAM"] + (it->second)["Cycles IFETCH served by L3 (No Snoop)"];
(it->second)["Local DRAM IFECTHes % Impact"] = (it->second)["Cycles IFETCH served by Local DRAM"] * 100 / (it->second)["Total L2 IFETCH miss Impact"];
(it->second)["L3 (Modified) IFECTHes % Impact"] = (it->second)["Cycles IFETCH served by L3 (Modified)"] * 100 / (it->second)["Total L2 IFETCH miss Impact"];
(it->second)["L3 (Clean Snoop) IFECTHes % Impact"] = (it->second)["Cycles IFETCH served by L3 (Clean Snoop)"] * 100 / (it->second)["Total L2 IFETCH miss Impact"];
(it->second)["Remote L2 IFECTHes % Impact"] = (it->second)["Cycles IFETCH served by Remote L2"] * 100 / (it->second)["Total L2 IFETCH miss Impact"];
(it->second)["Remote DRAM IFECTHes % Impact"] = (it->second)["Cycles IFETCH served by Remote DRAM"] * 100 / (it->second)["Total L2 IFETCH miss Impact"];
(it->second)["L3 (No Snoop) IFECTHes % Impact"] = (it->second)["Cycles IFETCH served by L3 (No Snoop)"] * 100 / (it->second)["Total L2 IFETCH miss Impact"];
(it->second)["Total L2 IFETCH misses"] = (it->second)["L2_RQSTS:IFETCH_MISS"];
(it->second)["% of IFETCHes served by Local DRAM"] = (it->second)["OFFCORE_RESPONSE_0:DMND_IFETCH:LOCAL_DRAM"] * 100 / (it->second)["L2_RQSTS:IFETCH_MISS"];
(it->second)["% of IFETCHes served by L3 (Modified)"] = (it->second)["OFFCORE_RESPONSE_0:DMND_IFETCH:OTHER_CORE_HITM"] * 100 / (it->second)["L2_RQSTS:IFETCH_MISS"];
(it->second)["% of IFETCHes served by L3 (Clean Snoop)"] = (it->second)["OFFCORE_RESPONSE_0:DMND_IFETCH:OTHER_CORE_HIT_SNP"] * 100 / (it->second)["L2_RQSTS:IFETCH_MISS"];
(it->second)["% of IFETCHes served by Remote L2"] = (it->second)["OFFCORE_RESPONSE_0:DMND_IFETCH:REMOTE_CACHE_FWD"] * 100 / (it->second)["L2_RQSTS:IFETCH_MISS"];
(it->second)["% of IFETCHes served by Remote DRAM"] = (it->second)["OFFCORE_RESPONSE_0:DMND_IFETCH:REMOTE_DRAM"] * 100 / (it->second)["L2_RQSTS:IFETCH_MISS"];
(it->second)["% of IFETCHes served by L3 (No Snoop)"] = (it->second)["OFFCORE_RESPONSE_0:DMND_IFETCH:UNCORE_HIT"] * 100 / (it->second)["L2_RQSTS:IFETCH_MISS"];
(it->second)["% of L2 IFETCH misses"] = (it->second)["L2_RQSTS:IFETCH_MISS"] * 100 / ((it->second)["L2_RQSTS:IFETCH_MISS"] + (it->second)["L2_RQSTS:IFETCH_HIT"]);
(it->second)["Total Branch Instructions Executed"] = (it->second)["BR_INST_EXEC:ANY"];
(it->second)["% of Mispredicted Branches"] = (it->second)["BR_MISP_EXEC:ANY"] * 100 / (it->second)["BR_INST_EXEC:ANY"];
(it->second)["Direct Near Calls % of Total Branches Executed"] = (it->second)["BR_INST_EXEC:DIRECT_NEAR_CALL"] * 100 / (it->second)["Total Branch Instructions Executed"];
(it->second)["Indirect Near Calls % of Total Branches Executed"] = (it->second)["BR_INST_EXEC:INDIRECT_NEAR_CALL"] * 100 / (it->second)["Total Branch Instructions Executed"];
(it->second)["Indirect Near Non-Calls % of Total Branches Executed"] = (it->second)["BR_INST_EXEC:INDIRECT_NON_CALL"] * 100 / (it->second)["Total Branch Instructions Executed"];
(it->second)["All Near Calls % of Total Branches Executed"] = (it->second)["BR_INST_EXEC:NEAR_CALLS"] * 100 / (it->second)["Total Branch Instructions Executed"];
(it->second)["All Non Calls % of Total Branches Executed"] = (it->second)["BR_INST_EXEC:NON_CALLS"] * 100 / (it->second)["Total Branch Instructions Executed"];
(it->second)["All Returns % of Total Branches Executed"] = (it->second)["BR_INST_EXEC:RETURN_NEAR"] * 100 / (it->second)["Total Branch Instructions Executed"];
(it->second)["Total Branch Instructions Retired"] = (it->second)["BR_INST_RETIRED:ALL_BRANCHES"];
(it->second)["Conditionals % of Total Branches Retired"] = (it->second)["BR_INST_RETIRED:CONDITIONAL"] * 100 / (it->second)["Total Branch Instructions Retired"];
(it->second)["Near Calls % of Total Branches Retired"] = (it->second)["BR_INST_RETIRED:NEAR_CALL"] * 100 / (it->second)["Total Branch Instructions Retired"];
(it->second)["Instruction Starvation % of Total Cycles"] = ((it->second)["UOPS_ISSUED:ANY CMASK=1 INV=1"] - (it->second)["RESOURCE_STALLS:ANY"])* 100 / (it->second)["CPU_CLK_UNHALTED:THREAD_P"];
(it->second)["% of Total Cycles spent handling FP exceptions"] = (it->second)["UOPS_DECODED:MS CMASK=1"]* 100 / (it->second)["CPU_CLK_UNHALTED:THREAD_P"];
(it->second)["# of Instructions per Call"] = (it->second)["INST_RETIRED:ANY_P"] / (it->second)["BR_INST_EXEC:NEAR_CALLS"];
(it->second)["Instructions Retired"] = (it->second)["INST_RETIRED:ANY_P"];
(it->second)["ITLB Miss Rate in %"] = ((it->second)["ITLB_MISS_RETIRED"] / (it->second)["INST_RETIRED:ANY_P"]) * 100;
(it->second)["Branch Instructions"] = (it->second)["BR_INST_RETIRED:ALL_BRANCHES"];
(it->second)["Load Instructions"] = (it->second)["MEM_INST_RETIRED:LOADS"];
(it->second)["Store Instructions"] = (it->second)["MEM_INST_RETIRED:STORES"];
(it->second)["Other Instructions"] = (it->second)["Instructions Retired"] - (it->second)["MEM_INST_RETIRED:LOADS"] - (it->second)["MEM_INST_RETIRED:STORES"] - (it->second)["BR_INST_RETIRED:ALL_BRANCHES"];
(it->second)["Packed UOPS Retired"] = (it->second)["SSEX_UOPS_RETIRED:PACKED_DOUBLE"] + (it->second)["SSEX_UOPS_RETIRED:PACKED_SINGLE"];
(it->second)["CPI"] = (it->second)["CPU_CLK_UNHALTED:THREAD_P"] / (it->second)["INST_RETIRED:ANY_P"];
double localPerformanceImprovement = (it->second)[
"CPI"]/
EXPECTED_CPI;
double cyclesAfterImprovement = (it->second)["CPU_CLK_UNHALTED:THREAD_P"]/localPerformanceImprovement;
double totalCyclesAfterImprovement = totalCycles-(it->second)["CPU_CLK_UNHALTED:THREAD_P"]+cyclesAfterImprovement;
(it->second)["iMargin"] = 100-(totalCyclesAfterImprovement/totalCycles)*100;
(it->second)["Load % of all Instructions"] = (it->second)["MEM_INST_RETIRED:LOADS"] * 100 / (it->second)["INST_RETIRED:ANY_P"];
(it->second)["Store % of all Instructions"] = (it->second)["MEM_INST_RETIRED:STORES"] * 100 / (it->second)["INST_RETIRED:ANY_P"];
(it->second)["Branch % of all Instructions"] = (it->second)["BR_INST_RETIRED:ALL_BRANCHES"] * 100 / (it->second)["INST_RETIRED:ANY_P"];
(it->second)["Other % of all Instructions"] = (it->second)["Other Instructions"] * 100 / (it->second)["INST_RETIRED:ANY_P"];
(it->second)["Packed % of all UOPS Retired"] = (it->second)["Packed UOPS Retired"] * 100 / (it->second)["UOPS_RETIRED:ANY"];
}
}
