NTuple::_ItemImp< TYP > Class Template Reference

Concrete class discribing a column in a N tuple. More...

#include </builds/gaudi/Gaudi/GaudiKernel/include/GaudiKernel/NTupleItems.h>

Public Types
typedef Range< TYP >	ItemRange
	Set type definition to make life more easy easy. More...

Public Member Functions
	_ItemImp (INTuple *tup, const std::string &name, const std::type_info &info, TYP min, TYP max, TYP def)
	Standard Constructor. More...
void	setDefault (const TYP val) override
	Compiler type ID. More...
const ItemRange &	range () const override
	Access the range if specified. More...
long	size () const override
	Size of entire object. More...

Detailed Description

template<class TYP>
class NTuple::_ItemImp< TYP >

Concrete class discribing a column in a N tuple.

Definition at line 48 of file NTupleItems.h.

Member Typedef Documentation

ItemRange

template<class TYP >

typedef Range<TYP> NTuple::_ItemImp< TYP >::ItemRange

Set type definition to make life more easy easy.

Definition at line 172 of file NTupleItems.h.

Constructor & Destructor Documentation

_ItemImp()

template<class TYP >

NTuple::_ItemImp< TYP >::_ItemImp ( INTuple *  tup, const std::string &  name, const std::type_info &  info, TYP  min, TYP  max, TYP  def  )

inline

Standard Constructor.

Definition at line 174 of file NTupleItems.h.

        : _DataImp<TYP>( tup, name, info, "", 1, min, max, def ) {}

Member Function Documentation

range()

template<class TYP >

const ItemRange& NTuple::_ItemImp< TYP >::range ( ) const

inlineoverride

Access the range if specified.

Definition at line 181 of file NTupleItems.h.

{ return this->m_range; }

setDefault()

template<class TYP >

void NTuple::_ItemImp< TYP >::setDefault ( const TYP  val )

inlineoverride

Compiler type ID.

Set default value

Definition at line 179 of file NTupleItems.h.

{ this->m_def = val; }

size()

template<class TYP >

long NTuple::_ItemImp< TYP >::size ( ) const

inlineoverride

Size of entire object.

Definition at line 183 of file NTupleItems.h.

{ return this->m_length * sizeof( TYP ); }

---

The documentation for this class was generated from the following file:

• GaudiKernel/include/GaudiKernel/NTupleItems.h
