NTuple::_ArrayImp< TYP > Class Template Reference

Concrete class discribing a column-array in a N tuple. More...

#include </builds/gaudi/Gaudi/GaudiKernel/include/GaudiKernel/NTupleItems.h>

Public Types
typedef Range< TYP >	ItemRange
	Set type definition to make life more easy easy. More...

Public Member Functions
	_ArrayImp (INTuple *tup, const std::string &name, const std::type_info &typ, const std::string &index, long len, TYP min, TYP max, TYP def)
	Standard Constructor. More...
void	setDefault (const TYP val) override
	Compiler type ID. More...
const ItemRange &	range () const override
	Access the range if specified. More...
long	size () const override
	Size of entire object. More...
long	ndim () const override
	Dimension. More...
long	dim (long i) const override
	Access individual dimensions. More...

Detailed Description

template<class TYP>
class NTuple::_ArrayImp< TYP >

Concrete class discribing a column-array in a N tuple.

Definition at line 50 of file NTupleItems.h.

Member Typedef Documentation

ItemRange

template<class TYP >

typedef Range<TYP> NTuple::_ArrayImp< TYP >::ItemRange

Set type definition to make life more easy easy.

Definition at line 192 of file NTupleItems.h.

Constructor & Destructor Documentation

_ArrayImp()

template<class TYP >

NTuple::_ArrayImp< TYP >::_ArrayImp ( INTuple *  tup, const std::string &  name, const std::type_info &  typ, const std::string &  index, long  len, TYP  min, TYP  max, TYP  def  )

inline

Standard Constructor.

Definition at line 194 of file NTupleItems.h.

        : _DataImp<TYP>( tup, name, typ, index, len, min, max, def ) {}

Member Function Documentation

dim()

template<class TYP >

long NTuple::_ArrayImp< TYP >::dim ( long  i ) const

inlineoverride

Access individual dimensions.

Definition at line 208 of file NTupleItems.h.

{ return ( i != 0 || this->hasIndex() ) ? 0 : this->m_length; }

ndim()

template<class TYP >

long NTuple::_ArrayImp< TYP >::ndim ( ) const

inlineoverride

Dimension.

Definition at line 206 of file NTupleItems.h.

{ return 1; }

range()

template<class TYP >

const ItemRange& NTuple::_ArrayImp< TYP >::range ( ) const

inlineoverride

Access the range if specified.

Definition at line 202 of file NTupleItems.h.

{ return this->m_range; }

setDefault()

template<class TYP >

void NTuple::_ArrayImp< TYP >::setDefault ( const TYP  val )

inlineoverride

Compiler type ID.

Set default value

Definition at line 200 of file NTupleItems.h.

{ this->m_def = val; }

size()

template<class TYP >

long NTuple::_ArrayImp< TYP >::size ( ) const

inlineoverride

Size of entire object.

Definition at line 204 of file NTupleItems.h.

{ return this->m_length * sizeof( TYP ); }

---

The documentation for this class was generated from the following file:

• GaudiKernel/include/GaudiKernel/NTupleItems.h
