HistogramSvc Class Reference

00384   : base_class(nam, svc)
00385   , m_defs1D ()
00386   , m_mods1D ()
00387 {
00388   // Properties can be declared here
00389   m_rootName = "/stat";
00390   m_rootCLID = CLID_DataObject;
00391   declareProperty ( "Input",  m_input);
00392   declareProperty ( "Predefined1DHistos" , m_defs1D ,
00393                     "Histograms with predefined parameters" ) ;
00394   // update handler
00395   Property* p = Gaudi::Utils::getProperty ( this , "Predefined1DHistos" ) ;
00396   p->declareUpdateHandler ( &HistogramSvc::update1Ddefs , this ) ;
00397
00398 }

HistogramSvc::~HistogramSvc ( ) [virtual]

Destructor.

Definition at line 201 of file HistogramSvc.cpp.

00201                               {
00202   setDataLoader( 0 ).ignore();
00203   clearStore().ignore();
00204 }

Member Function Documentation

void HistogramSvc::not_implemented ( ) const [inline, private]

Definition at line 57 of file HistogramSvc.h.

00057                                 {
00058     MsgStream log( msgSvc(), name() );
00059     log << MSG::ERROR << "Sorry, not yet implemented..." << endmsg;
00060   }

std::pair< std::string, std::string > HistogramSvc::i_splitPath ( CSTR full )

Split full path into its components.

Parameters:

	full	Full path of the object
	dir	Resulting directory path
	obj	Resulting object path

Definition at line 130 of file HistogramSvc.cpp.

00130                                                                   {
00131   std::string tmp = full;
00132   if (tmp[0] != SEPARATOR)    {
00133     tmp.insert(tmp.begin(), SEPARATOR);
00134     tmp.insert(tmp.begin(), m_rootName.begin(), m_rootName.end());
00135   }
00136   // Remove trailing "/" from newPath if it exists
00137   if (tmp.rfind(SEPARATOR) == tmp.length()-1) {
00138     tmp.erase(tmp.rfind(SEPARATOR),1);
00139   }
00140   int sep = tmp.rfind(SEPARATOR);
00141   return std::pair<std::string,std::string>
00142     (tmp.substr(0,sep),tmp.substr(sep,tmp.length()-sep));
00143 }

StatusCode HistogramSvc::connectInput ( CSTR ident )

Connect input histogram file to the service.

Parameters:

ident

[IN] Input specification

Definition at line 206 of file HistogramSvc.cpp.

00206                                                 {
00207   MsgStream log (msgSvc(), name());
00208   DataObject* pO = 0;
00209   StatusCode status = this->findObject(m_rootName, pO);
00210   if (status.isSuccess())   {
00211     Tokenizer tok(true);
00212     std::string::size_type loc = ident.find(" ");
00213     std::string filename, auth, svc = "", typ = "";
00214     std::string logname = ident.substr(0,loc);
00215     tok.analyse(ident.substr(loc+1,ident.length()), " ", "", "", "=", "'", "'");
00216     for (Tokenizer::Items::iterator i = tok.items().begin();
00217          i != tok.items().end(); i++) {
00218       CSTR tag = (*i).tag();
00219       switch(::toupper(tag[0]))   {
00220       case 'F':   // FILE='<file name>'
00221       case 'D':   // DATAFILE='<file name>'
00222         filename = (*i).value();
00223         break;
00224       case 'T':   // TYP='<HBOOK,ROOT,OBJY,...>'
00225         typ = (*i).value();
00226         break;
00227       default:
00228         break;
00229       }
00230     }
00231     if (typ.length() > 0)    {
00232       // Now add the registry entry to the store
00233       std::string entryname = m_rootName;
00234       entryname += '/';
00235       entryname += logname;
00236       GenericAddress* pA = 0;
00237       switch(::toupper(typ[0])) {
00238       case 'H':
00239         pA=new GenericAddress(HBOOK_StorageType,CLID_StatisticsFile,
00240                               filename,entryname,0,'O');
00241         break;
00242       case 'R':
00243         pA=new GenericAddress(ROOT_StorageType,CLID_StatisticsFile,
00244                               filename,entryname,0,'O');
00245         break;
00246       }
00247       if (0 != pA)    {
00248         status = registerAddress(pO, logname, pA);
00249         if (status.isSuccess())    {
00250           log << MSG::INFO << "Added stream file:" << filename
00251               << " as " << logname << endmsg;
00252           return status;
00253         }
00254         pA->release();
00255       }
00256     }
00257   }
00258   log << MSG::ERROR << "Cannot add " << ident << " invalid filename!" << endmsg;
00259   return StatusCode::FAILURE;
00260 }

std::string HistogramSvc::_STR ( int i )

Definition at line 57 of file HistogramSvc.cpp.

00057                                    {
00058   char txt[32];
00059   return _itoa(i, txt, 10);
00060 }

template<class T>

T* HistogramSvc::i_book	(	DataObject *	pPar,
		CSTR	rel,
		CSTR	title,
		const std::pair< DataObject , T > &	o
	)			`[inline]`

Definition at line 148 of file HistogramSvc.h.

00148                                                                                     {
00149     if (o.first && registerObject(pPar, rel, (Base*)o.second).isSuccess())
00150       return o.second;
00151     delete o.first;
00152     throw GaudiException("Cannot book "+System::typeinfoName(typeid(T))+" "+title,
00153       "HistogramSvc",StatusCode::FAILURE);
00154   }

template<class T>

static DataObject* HistogramSvc::__cast ( T * p ) [inline, static]

Definition at line 155 of file HistogramSvc.h.

00155                                                       {
00156     DataObject* q = dynamic_cast<DataObject*>(p);
00157     if ( 0 == q && 0 != p )  {
00158       throw std::runtime_error("HistogramSvc: Unexpected object type.");
00159     }
00160     return q;
00161   }

H2D* HistogramSvc::i_project	(	CSTR	nameAndTitle,
		const H3D &	h,
		CSTR	dir
	)

Helper for 2D projections.

StatusCode HistogramSvc::initialize ( ) [virtual]

Initialise the service.

Reimplemented from DataSvc.

Definition at line 262 of file HistogramSvc.cpp.

00262                                       {
00263   MsgStream log(msgSvc(), name());
00264   StatusCode status = DataSvc::initialize();
00265   // Set root object
00266   if (status.isSuccess()) {
00267     DataObject* rootObj = new DataObject();
00268     status = setRoot("/stat", rootObj);
00269     if (!status.isSuccess()) {
00270       log << MSG::ERROR << "Unable to set hstogram data store root." << endmsg;
00271       delete rootObj;
00272       return status;
00273     }
00274     IConversionSvc* svc = 0;
00275     status = service("HistogramPersistencySvc",svc,true);
00276     if ( status.isSuccess() )   {
00277       setDataLoader( svc ).ignore();
00278       svc->release();
00279     }
00280     else  {
00281       log << MSG::ERROR << "Could not find HistogramPersistencySvc." << endmsg;
00282       return status;
00283     }
00284     // Connect all input streams (if any)
00285     for (DBaseEntries::iterator j = m_input.begin(); j != m_input.end(); j++)    {
00286       status = connectInput(*j);
00287       if (!status.isSuccess())  {
00288         return status;
00289       }
00290     }
00291   }
00292   if ( !m_defs1D.empty() )
00293   {
00294     log << MSG::INFO << " Predefined 1D-Histograms: " << endmsg ;
00295     for ( Histo1DMap::const_iterator ih = m_defs1D.begin() ;
00296           m_defs1D.end() != ih ; ++ih )
00297     {
00298       log << MSG::INFO
00299           << " Path='"       << ih->first  << "'"
00300           << " Description " << ih->second << endmsg ;
00301     }
00302   }
00303   return status;
00304 }

StatusCode HistogramSvc::reinitialize ( ) [virtual]

Initialise the service.

Reimplemented from DataSvc.

Definition at line 306 of file HistogramSvc.cpp.

00306                                         {
00307   return StatusCode::SUCCESS;
00308 }

StatusCode HistogramSvc::finalize ( void ) [virtual]

finalize the service

Reimplemented from DataSvc.

Definition at line 430 of file HistogramSvc.cpp.

00431 {
00432   if ( !m_mods1D.empty() )
00433   {
00434     MsgStream log ( msgSvc () , name () ) ;
00435     log << MSG::DEBUG
00436         << " Substituted histograms #" << m_mods1D.size() << " : " << endmsg ;
00437     for ( std::set<std::string>::const_iterator ih = m_mods1D.begin() ;
00438           m_mods1D.end() != ih ; ++ih )
00439     {
00440       log << MSG::DEBUG << " Path='" << (*ih) << "'" ;
00441       Histo1DMap::const_iterator im = m_defs1D.find( *ih ) ;
00442       if ( m_defs1D.end() != im ) { log << "  " << im->second ; }
00443     }
00444     m_mods1D.clear() ;
00445   }
00446   return DataSvc::finalize () ;
00447 }

virtual AIDA::IHistogramFactory* HistogramSvc::histogramFactory ( ) [inline, virtual]

Retrieve the AIDA HistogramFactory interface.

Implements IHistogramSvc.

Definition at line 174 of file HistogramSvc.h.

00174 {  return this; }

virtual H1D* HistogramSvc::book	(	CSTR	par,
		CSTR	rel,
		CSTR	title,
		DBINS(x)
	)			`[inline, virtual]`

Book histogram and register it with the histogram data store.

Parameters:

	full	Full path to the node of the object. The basename (last part of the fullpath) has to be an integer number otherwise conversion to HBOOK is not possible)
	par	Path to parent node of the object, the directory the histogram will be stored in.
	pPar	Pointer to parent node
	rel	Histogram identifier (std::string), the relative path to the object with respect to the parent node
	hID	Histogram identifier (int) of the histogram
	title	Title property of the histogram
	DBINS(x)	Macro for bin definition. Expands to: int nx: Number of bins on the axis X/Y double lx: Lower histogram edge on the axis X/Y double ux: Upper histogram edge on the axis X/Y

Definition at line 196 of file HistogramSvc.h.

00197   {  return book(createPath(par), rel, title, BINS(x));                          }

virtual H1D* HistogramSvc::book	(	CSTR	par,
		int	hID,
		CSTR	title,
		DBINS(x)
	)			`[inline, virtual]`

Definition at line 198 of file HistogramSvc.h.

00199   {  return book(par, _STR(hID), title, BINS(x));                                }

virtual H1D* HistogramSvc::book	(	DataObject *	pPar,
		int	hID,
		CSTR	title,
		DBINS(x)
	)			`[inline, virtual]`

Definition at line 200 of file HistogramSvc.h.

00201   {  return book(pPar, _STR(hID), title, BINS(x));                               }

AIDA::IHistogram1D * HistogramSvc::book	(	DataObject *	pPar,
		CSTR	rel,
		CSTR	title,
		DBINS(x)
	)			`[virtual]`

Definition at line 359 of file HistogramSvc.cpp.

00360 {
00361   if ( m_defs1D.empty () )
00362   { return i_book(pPar,rel,title,Gaudi::createH1D(title, BINS(x))); }
00363   std::string hn = histoAddr ( pPar , rel ) ;
00364   Histo1DMap::const_iterator ifound = m_defs1D.find( hn ) ;
00365   if ( m_defs1D.end() == ifound )
00366   { return i_book(pPar,rel,title,Gaudi::createH1D(title, BINS(x))); }
00367   MsgStream log ( msgSvc() , name() ) ;
00368   log << MSG::DEBUG
00369       << " Redefine the parameters for the histogram '" + hn +"' to be "
00370       << ifound->second
00371       << endmsg ;
00372   m_mods1D.insert ( hn ) ;
00373   return i_book ( pPar , rel , ifound -> second.title   () ,
00374                   Gaudi::createH1D
00375                   ( ifound -> second.title   () ,
00376                     ifound -> second.bins    () ,
00377                     ifound -> second.lowEdge () ,
00378                     ifound -> second.lowEdge () ) ) ;
00379 }

virtual H1D* HistogramSvc::book	(	STRPAIR	loc,
		CSTR	title,
		DBINS(x)
	)			`[inline, virtual]`

Definition at line 203 of file HistogramSvc.h.

00204   { return book(loc.first, loc.second, title, BINS(x));                          }

virtual H1D* HistogramSvc::book	(	CSTR	full,
		CSTR	title,
		DBINS(x)
	)			`[inline, virtual]`

Definition at line 205 of file HistogramSvc.h.

00206   { return book(i_splitPath(full), title, BINS(x));                              }

virtual P1D* HistogramSvc::bookProf	(	CSTR	par,
		CSTR	rel,
		CSTR	title,
		DBINS(x)	,
		CSTR	opt
	)			`[inline, virtual]`

Book histogram and register it with the histogram data store.

Parameters:

	full	Full path to the node of the object. The basename (last part of the fullpath) has to be an integer number (otherwise conversion to HBOOK is not possible)
	par	Path to parent node of the object, the directory the histogram will be stored in.
	pPar	Pointer to parent node
	rel	Histogram identifier (std::string), the relative path to the object with respect to the parent node
	hID	Histogram identifier (int) of the histogram
	title	Title property of the histogram
	DBINS(x)	Macro for bin definition. Expands to: int nx: Number of bins on the axis X/Y double lx: Lower histogram edge on the axis X/Y double ux: Upper histogram edge on the axis X/Y

Definition at line 227 of file HistogramSvc.h.

00228   { return bookProf(createPath(par), rel, title, BINS(x),opt);                     }

virtual P1D* HistogramSvc::bookProf	(	CSTR	par,
		int	hID,
		CSTR	title,
		DBINS(x)	,
		CSTR	opt
	)			`[inline, virtual]`

Definition at line 229 of file HistogramSvc.h.

00230   { return bookProf(par, _STR(hID), title, BINS(x),opt);                           }

virtual P1D* HistogramSvc::bookProf	(	DataObject *	pPar,
		int	hID,
		CSTR	title,
		DBINS(x)	,
		CSTR	opt
	)			`[inline, virtual]`

Definition at line 231 of file HistogramSvc.h.

00232   { return bookProf(pPar, _STR(hID), title, BINS(x),opt);                          }

virtual P1D* HistogramSvc::bookProf	(	STRPAIR	loc,
		CSTR	title,
		DBINS(x)	,
		CSTR	opt
	)			`[inline, virtual]`

Definition at line 233 of file HistogramSvc.h.

00234   { return bookProf(loc.first, loc.second, title, BINS(x),opt);                    }

virtual P1D* HistogramSvc::bookProf	(	CSTR	full,
		CSTR	title,
		DBINS(x)	,
		CSTR	opt
	)			`[inline, virtual]`

Definition at line 235 of file HistogramSvc.h.

00236   { return bookProf(i_splitPath(full), title, BINS(x),opt);                        }

virtual P1D* HistogramSvc::bookProf	(	DataObject *	pPar,
		CSTR	rel,
		CSTR	title,
		DBINS(x)	,
		CSTR	opt
	)			`[inline, virtual]`

Definition at line 237 of file HistogramSvc.h.

00238   { return i_book(pPar,rel,title,Gaudi::createProf1D(title, BINS(x),0,0,opt));     }

virtual P1D* HistogramSvc::bookProf	(	CSTR	par,
		CSTR	rel,
		CSTR	title,
		DBINS(x)	,
		double	upper,
		double	lower,
		CSTR	opt
	)			`[inline, virtual]`

Definition at line 240 of file HistogramSvc.h.

00241   { return bookProf(createPath(par), rel, title, BINS(x), upper, lower , opt);                     }

virtual P1D* HistogramSvc::bookProf	(	CSTR	par,
		int	hID,
		CSTR	title,
		DBINS(x)	,
		double	upper,
		double	lower,
		CSTR	opt
	)			`[inline, virtual]`

Definition at line 242 of file HistogramSvc.h.

00243   { return bookProf(par, _STR(hID), title, BINS(x), upper, lower, opt );                           }

virtual P1D* HistogramSvc::bookProf	(	DataObject *	pPar,
		int	hID,
		CSTR	title,
		DBINS(x)	,
		double	upper,
		double	lower,
		CSTR	opt
	)			`[inline, virtual]`

Definition at line 244 of file HistogramSvc.h.

00245   { return bookProf(pPar, _STR(hID), title, BINS(x), upper, lower, opt);                          }

virtual P1D* HistogramSvc::bookProf	(	STRPAIR	loc,
		CSTR	title,
		DBINS(x)	,
		double	upper,
		double	lower,
		CSTR	opt
	)			`[inline, virtual]`

Definition at line 246 of file HistogramSvc.h.

00247   { return bookProf(loc.first, loc.second, title, BINS(x), upper, lower,opt);                    }

virtual P1D* HistogramSvc::bookProf	(	CSTR	full,
		CSTR	title,
		DBINS(x)	,
		double	upper,
		double	lower,
		CSTR	opt
	)			`[inline, virtual]`

Definition at line 248 of file HistogramSvc.h.

00249   { return bookProf(i_splitPath(full), title, BINS(x), upper, lower , opt );                        }

virtual P1D* HistogramSvc::bookProf	(	DataObject *	pPar,
		CSTR	rel,
		CSTR	title,
		DBINS(x)	,
		double	upper,
		double	lower,
		CSTR	opt
	)			`[inline, virtual]`

Definition at line 250 of file HistogramSvc.h.

00251   { return i_book(pPar,rel,title,Gaudi::createProf1D(title, BINS(x), upper, lower, opt));         }

virtual H1D* HistogramSvc::book	(	CSTR	par,
		int	hID,
		CSTR	title,
		Edges	e
	)			`[inline, virtual]`

Book histogram and register it with the histogram data store.

Parameters:

	full	Full path to the node of the object. The basename (last part of the fullpath) has to be an integer number (otherwise conversion to HBOOK is not possible)
	par	Path to parent node of the object, the directory the histogram will be stored in.
	pPar	Pointer to parent node
	rel	Histogram identifier (std::string), the relative path to the object with respect to the parent node
	hID	Histogram identifier (int) of the histogram
	title	Title property of the histogram
	e	Bin edges for variable binned histogram.

Definition at line 269 of file HistogramSvc.h.

00270   {  return book(par, _STR(hID), title, e);                                 }

virtual H1D* HistogramSvc::book	(	DataObject *	pPar,
		int	hID,
		CSTR	title,
		Edges	e
	)			`[inline, virtual]`

Definition at line 271 of file HistogramSvc.h.

00272   {  return book(pPar, _STR(hID), title, e);                                }

virtual H1D* HistogramSvc::book	(	CSTR	par,
		CSTR	rel,
		CSTR	title,
		Edges	e
	)			`[inline, virtual]`

Definition at line 273 of file HistogramSvc.h.

00274   {  return book(createPath(par), rel, title, e);                           }

virtual H1D* HistogramSvc::book	(	STRPAIR	loc,
		CSTR	title,
		Edges	e
	)			`[inline, virtual]`

Definition at line 275 of file HistogramSvc.h.

00276   { return book(loc.first, loc.second, title, e);                           }

virtual H1D* HistogramSvc::book	(	CSTR	full,
		CSTR	title,
		Edges	e
	)			`[inline, virtual]`

Definition at line 277 of file HistogramSvc.h.

00278   { return book(i_splitPath(full), title, e);                               }

virtual H1D* HistogramSvc::book	(	DataObject *	pPar,
		CSTR	rel,
		CSTR	title,
		Edges	e
	)			`[inline, virtual]`

Definition at line 279 of file HistogramSvc.h.

00280   { return i_book(pPar, rel, title, Gaudi::createH1D(title, e));            }

virtual P1D* HistogramSvc::bookProf	(	CSTR	full,
		CSTR	title,
		Edges	e
	)			`[inline, virtual]`

Book histogram and register it with the histogram data store.

Parameters:

	full	Full path to the node of the object. The basename (last part of the full) has to be an integer number (otherwise conversion to HBOOK is not possible)
	par	Path to parent node of the object, the directory the histogram will be stored in.
	pPar	Pointer to parent node
	rel	Histogram identifier (std::string), the relative path to the object with respect to the parent node
	hID	Histogram identifier (int) of the histogram
	title	Title property of the histogram
	e	Bin edges for variable binned histogram.

Definition at line 299 of file HistogramSvc.h.

00300   { return bookProf(i_splitPath(full), title, e);                             }

virtual P1D* HistogramSvc::bookProf	(	CSTR	par,
		CSTR	rel,
		CSTR	title,
		Edges	e
	)			`[inline, virtual]`

Definition at line 301 of file HistogramSvc.h.

00302   { return bookProf(createPath(par), rel, title, e);                          }

virtual P1D* HistogramSvc::bookProf	(	CSTR	par,
		int	hID,
		CSTR	title,
		Edges	e
	)			`[inline, virtual]`

Definition at line 303 of file HistogramSvc.h.

00304   { return bookProf(par, _STR(hID), title, e);                                }

virtual P1D* HistogramSvc::bookProf	(	DataObject *	pPar,
		int	hID,
		CSTR	title,
		Edges	e
	)			`[inline, virtual]`

Definition at line 305 of file HistogramSvc.h.

00306   { return bookProf(pPar, _STR(hID), title, e);                               }

virtual P1D* HistogramSvc::bookProf	(	STRPAIR	loc,
		CSTR	title,
		Edges	e
	)			`[inline, virtual]`

Definition at line 307 of file HistogramSvc.h.

00308   { return bookProf(loc.first, loc.second, title, e);                         }

virtual P1D* HistogramSvc::bookProf	(	DataObject *	pPar,
		CSTR	rel,
		CSTR	title,
		Edges	e
	)			`[inline, virtual]`

Definition at line 309 of file HistogramSvc.h.

00310   { return i_book(pPar,rel,title,Gaudi::createProf1D(title, e, 0, 0));        }

virtual P1D* HistogramSvc::bookProf	(	CSTR	full,
		CSTR	title,
		Edges	e,
		double	upper,
		double	lower
	)			`[inline, virtual]`

Definition at line 312 of file HistogramSvc.h.

00313   { return bookProf(i_splitPath(full), title, e, upper, lower);               }

virtual P1D* HistogramSvc::bookProf	(	CSTR	par,
		CSTR	rel,
		CSTR	title,
		Edges	e,
		double	upper,
		double	lower
	)			`[inline, virtual]`

Definition at line 314 of file HistogramSvc.h.

00315   { return bookProf(createPath(par), rel, title, e, upper, lower);            }

virtual P1D* HistogramSvc::bookProf	(	CSTR	par,
		int	hID,
		CSTR	title,
		Edges	e,
		double	upper,
		double	lower
	)			`[inline, virtual]`

Definition at line 316 of file HistogramSvc.h.

00317   { return bookProf(par, _STR(hID), title, e, upper, lower);                  }

virtual P1D* HistogramSvc::bookProf	(	DataObject *	pPar,
		int	hID,
		CSTR	title,
		Edges	e,
		double	upper,
		double	lower
	)			`[inline, virtual]`

Definition at line 318 of file HistogramSvc.h.

00319   { return bookProf(pPar, _STR(hID), title, e, upper, lower);                 }

virtual P1D* HistogramSvc::bookProf	(	STRPAIR	loc,
		CSTR	title,
		Edges	e,
		double	upper,
		double	lower
	)			`[inline, virtual]`

Definition at line 320 of file HistogramSvc.h.

00321   { return bookProf(loc.first, loc.second, title, e, upper, lower);           }

virtual P1D* HistogramSvc::bookProf	(	DataObject *	pPar,
		CSTR	rel,
		CSTR	title,
		Edges	e,
		double	upper,
		double	lower
	)			`[inline, virtual]`

Definition at line 322 of file HistogramSvc.h.

00323   { return i_book(pPar,rel,title,Gaudi::createProf1D(title, e, upper, lower));}

virtual H2D* HistogramSvc::book	(	CSTR	full,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)
	)			`[inline, virtual]`

Book histogram and register it with the histogram data store.

Parameters:

	full	Full path to the node of the object. The basename (last part of the full) has to be an integer number (otherwise conversion to HBOOK is not possible)
	par	Path to parent node of the object, the directory the histogram will be stored in.
	pPar	Pointer to parent node
	rel	Histogram identifier (std::string), the relative path to the object with respect to the parent node
	hID	Histogram identifier (int) of the histogram
	title	Title property of the histogram
	DBINS(x/y)	Macro for bin definition in X/Y. Expands to: int nx: Number of bins on the axis X/Y double lx: Lower histogram edge on the axis X/Y double ux: Upper histogram edge on the axis X/Y

Definition at line 344 of file HistogramSvc.h.

00345   { return book(i_splitPath(full), title, BINS(x),BINS(y));               }

virtual H2D* HistogramSvc::book	(	CSTR	par,
		CSTR	rel,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)
	)			`[inline, virtual]`

Definition at line 346 of file HistogramSvc.h.

00347   { return book(createPath(par), rel, title, BINS(x),BINS(y));            }

virtual H2D* HistogramSvc::book	(	CSTR	par,
		int	hID,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)
	)			`[inline, virtual]`

Definition at line 348 of file HistogramSvc.h.

00349   { return book(par,_STR(hID), title, BINS(x),BINS(y));                   }

virtual H2D* HistogramSvc::book	(	STRPAIR	loc,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)
	)			`[inline, virtual]`

Definition at line 350 of file HistogramSvc.h.

00351   { return book(loc.first, loc.second, title, BINS(x), BINS(y));          }

virtual H2D* HistogramSvc::book	(	DataObject *	pPar,
		int	hID,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)
	)			`[inline, virtual]`

Definition at line 352 of file HistogramSvc.h.

00353   { return book(pPar,_STR(hID), title, BINS(x),BINS(y));                  }

virtual H2D* HistogramSvc::book	(	DataObject *	pPar,
		CSTR	rel,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)
	)			`[inline, virtual]`

Definition at line 354 of file HistogramSvc.h.

00355   { return i_book(pPar,rel,title,Gaudi::createH2D(title, BINS(x),BINS(y)));}

virtual P2D* HistogramSvc::bookProf	(	CSTR	full,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)	,
		double	upper,
		double	lower
	)			`[inline, virtual]`

Book histogram and register it with the histogram data store.

Parameters:

	full	Full path to the node of the object. The basename (last part of the full) has to be an integer number (otherwise conversion to HBOOK is not possible)
	par	Path to parent node of the object, the directory the histogram will be stored in.
	pPar	Pointer to parent node
	rel	Histogram identifier (std::string), the relative path to the object with respect to the parent node
	hID	Histogram identifier (int) of the histogram
	title	Title property of the histogram
	DBINS(x/y)	Macro for bin definition in X/Y. Expands to: int nx: Number of bins on the axis X/Y double lx: Lower histogram edge on the axis X/Y double ux: Upper histogram edge on the axis X/Y

Definition at line 376 of file HistogramSvc.h.

00377   { return bookProf(i_splitPath(full), title, BINS(x),BINS(y), upper, lower);               }

virtual P2D* HistogramSvc::bookProf	(	CSTR	par,
		CSTR	rel,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)	,
		double	upper,
		double	lower
	)			`[inline, virtual]`

Definition at line 378 of file HistogramSvc.h.

00379   { return bookProf(createPath(par), rel, title, BINS(x),BINS(y), upper, lower);            }

virtual P2D* HistogramSvc::bookProf	(	STRPAIR	loc,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)	,
		double	upper,
		double	lower
	)			`[inline, virtual]`

Definition at line 380 of file HistogramSvc.h.

00381   { return bookProf(loc.first, loc.second, title, BINS(x), BINS(y), upper, lower);          }

virtual P2D* HistogramSvc::bookProf	(	CSTR	par,
		int	hID,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)	,
		double	upper,
		double	lower
	)			`[inline, virtual]`

Definition at line 382 of file HistogramSvc.h.

00383   { return bookProf(par, _STR(hID), title, BINS(x),BINS(y), upper, lower);                  }

virtual P2D* HistogramSvc::bookProf	(	DataObject *	pPar,
		int	hID,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)	,
		double	upper,
		double	lower
	)			`[inline, virtual]`

Definition at line 384 of file HistogramSvc.h.

00385   { return bookProf(pPar,_STR(hID), title, BINS(x),BINS(y), upper, lower);                  }

virtual P2D* HistogramSvc::bookProf	(	DataObject *	pPar,
		CSTR	rel,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)	,
		double	upper,
		double	lower
	)			`[inline, virtual]`

Definition at line 386 of file HistogramSvc.h.

00387   { return i_book(pPar,rel,title,Gaudi::createProf2D(title, BINS(x),BINS(y), upper, lower));  }

virtual P2D* HistogramSvc::bookProf	(	CSTR	full,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)
	)			`[inline, virtual]`

Definition at line 389 of file HistogramSvc.h.

00390   { return bookProf(i_splitPath(full), title, BINS(x),BINS(y));               }

virtual P2D* HistogramSvc::bookProf	(	CSTR	par,
		CSTR	rel,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)
	)			`[inline, virtual]`

Definition at line 391 of file HistogramSvc.h.

00392   { return bookProf(createPath(par), rel, title, BINS(x),BINS(y));            }

virtual P2D* HistogramSvc::bookProf	(	STRPAIR	loc,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)
	)			`[inline, virtual]`

Definition at line 393 of file HistogramSvc.h.

00394   { return bookProf(loc.first, loc.second, title, BINS(x), BINS(y));          }

virtual P2D* HistogramSvc::bookProf	(	CSTR	par,
		int	hID,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)
	)			`[inline, virtual]`

Definition at line 395 of file HistogramSvc.h.

00396   { return bookProf(par, _STR(hID), title, BINS(x),BINS(y));                  }

virtual P2D* HistogramSvc::bookProf	(	DataObject *	pPar,
		int	hID,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)
	)			`[inline, virtual]`

Definition at line 397 of file HistogramSvc.h.

00398   { return bookProf(pPar,_STR(hID), title, BINS(x),BINS(y));                  }

virtual P2D* HistogramSvc::bookProf	(	DataObject *	pPar,
		CSTR	rel,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)
	)			`[inline, virtual]`

Definition at line 399 of file HistogramSvc.h.

00400   { return i_book(pPar,rel,title,Gaudi::createProf2D(title, BINS(x),BINS(y),0,0));}

virtual H2D* HistogramSvc::book	(	CSTR	full,
		CSTR	title,
		Edges	x,
		Edges	y
	)			`[inline, virtual]`

Book histogram and register it with the histogram data store.

Parameters:

	full	Full path to the node of the object. The basename (last part of the full) has to be an integer number (otherwise conversion to HBOOK is not possible)
	par	Path to parent node of the object, the directory the histogram will be stored in.
	pPar	Pointer to parent node
	rel	Histogram identifier (std::string), the relative path to the object with respect to the parent node
	hID	Histogram identifier (int) of the histogram
	title	Title property of the histogram
	x/y	Bin edges for variable binned histogram in X/Y.

Definition at line 418 of file HistogramSvc.h.

00419   { return book(i_splitPath(full), title, x, y);                        }

virtual H2D* HistogramSvc::book	(	CSTR	par,
		CSTR	rel,
		CSTR	title,
		Edges	x,
		Edges	y
	)			`[inline, virtual]`

Definition at line 420 of file HistogramSvc.h.

00421   { return book(createPath(par), rel, title, x, y);                     }

virtual H2D* HistogramSvc::book	(	CSTR	par,
		int	hID,
		CSTR	title,
		Edges	x,
		Edges	y
	)			`[inline, virtual]`

Definition at line 422 of file HistogramSvc.h.

00423   { return book(par, _STR(hID), title, x, y);                           }

virtual H2D* HistogramSvc::book	(	STRPAIR	loc,
		CSTR	title,
		Edges	x,
		Edges	y
	)			`[inline, virtual]`

Definition at line 424 of file HistogramSvc.h.

00425   { return book(loc.first, loc.second, title, x, y);                    }

virtual H2D* HistogramSvc::book	(	DataObject *	pPar,
		int	hID,
		CSTR	title,
		Edges	x,
		Edges	y
	)			`[inline, virtual]`

Definition at line 426 of file HistogramSvc.h.

00427   { return book(pPar, _STR(hID), title, x, y);                          }

virtual H2D* HistogramSvc::book	(	DataObject *	pPar,
		CSTR	rel,
		CSTR	title,
		Edges	x,
		Edges	y
	)			`[inline, virtual]`

Definition at line 428 of file HistogramSvc.h.

00429   { return i_book(pPar, rel, title, Gaudi::createH2D(title, x,y));      }

virtual P2D* HistogramSvc::bookProf	(	CSTR	full,
		CSTR	title,
		Edges	x,
		Edges	y
	)			`[inline, virtual]`

Book histogram and register it with the histogram data store.

Parameters:

	full	Full path to the node of the object. The basename (last part of the full) has to be an integer number (otherwise conversion to HBOOK is not possible)
	par	Path to parent node of the object, the directory the histogram will be stored in.
	pPar	Pointer to parent node
	rel	Histogram identifier (std::string), the relative path to the object with respect to the parent node
	hID	Histogram identifier (int) of the histogram
	title	Title property of the histogram
	x/y	Bin edges for variable binned histogram in X/Y.

Definition at line 447 of file HistogramSvc.h.

00448   { return bookProf(i_splitPath(full), title, x, y);                    }

virtual P2D* HistogramSvc::bookProf	(	CSTR	par,
		CSTR	rel,
		CSTR	title,
		Edges	x,
		Edges	y
	)			`[inline, virtual]`

Definition at line 449 of file HistogramSvc.h.

00450   { return bookProf(createPath(par), rel, title, x, y);                  }

virtual P2D* HistogramSvc::bookProf	(	CSTR	par,
		int	hID,
		CSTR	title,
		Edges	x,
		Edges	y
	)			`[inline, virtual]`

Definition at line 451 of file HistogramSvc.h.

00452   { return bookProf(par, _STR(hID), title, x, y);                        }

virtual P2D* HistogramSvc::bookProf	(	DataObject *	pPar,
		int	hID,
		CSTR	title,
		Edges	x,
		Edges	y
	)			`[inline, virtual]`

Definition at line 453 of file HistogramSvc.h.

00454   { return bookProf(pPar, _STR(hID), title, x, y);                       }

virtual P2D* HistogramSvc::bookProf	(	STRPAIR	loc,
		CSTR	title,
		Edges	x,
		Edges	y
	)			`[inline, virtual]`

Definition at line 455 of file HistogramSvc.h.

00456   { return bookProf(loc.first, loc.second, title, x, y);                 }

virtual P2D* HistogramSvc::bookProf	(	DataObject *	pPar,
		CSTR	rel,
		CSTR	title,
		Edges	x,
		Edges	y
	)			`[inline, virtual]`

Definition at line 457 of file HistogramSvc.h.

00458   { return i_book(pPar, rel, title, Gaudi::createProf2D(title,x,y,0,0)); }

virtual P2D* HistogramSvc::bookProf	(	CSTR	full,
		CSTR	title,
		Edges	x,
		Edges	y,
		double	upper,
		double	lower
	)			`[inline, virtual]`

Definition at line 460 of file HistogramSvc.h.

00461   { return bookProf(i_splitPath(full), title, x, y, upper, lower);       }

virtual P2D* HistogramSvc::bookProf	(	CSTR	par,
		CSTR	rel,
		CSTR	title,
		Edges	x,
		Edges	y,
		double	upper,
		double	lower
	)			`[inline, virtual]`

Definition at line 462 of file HistogramSvc.h.

00463   { return bookProf(createPath(par), rel, title, x, y, upper, lower);                  }

virtual P2D* HistogramSvc::bookProf	(	CSTR	par,
		int	hID,
		CSTR	title,
		Edges	x,
		Edges	y,
		double	upper,
		double	lower
	)			`[inline, virtual]`

Definition at line 464 of file HistogramSvc.h.

00465   { return bookProf(par, _STR(hID), title, x, y, upper, lower);                        }

virtual P2D* HistogramSvc::bookProf	(	DataObject *	pPar,
		int	hID,
		CSTR	title,
		Edges	x,
		Edges	y,
		double	upper,
		double	lower
	)			`[inline, virtual]`

Definition at line 466 of file HistogramSvc.h.

00467   { return bookProf(pPar, _STR(hID), title, x, y, upper, lower);                       }

virtual P2D* HistogramSvc::bookProf	(	STRPAIR	loc,
		CSTR	title,
		Edges	x,
		Edges	y,
		double	upper,
		double	lower
	)			`[inline, virtual]`

Definition at line 468 of file HistogramSvc.h.

00469   { return bookProf(loc.first, loc.second, title, x, y, upper, lower);                 }

virtual P2D* HistogramSvc::bookProf	(	DataObject *	pPar,
		CSTR	rel,
		CSTR	title,
		Edges	x,
		Edges	y,
		double	upper,
		double	lower
	)			`[inline, virtual]`

Definition at line 470 of file HistogramSvc.h.

00471   { return i_book(pPar, rel, title, Gaudi::createProf2D(title,x,y, upper, lower));     }

virtual H3D* HistogramSvc::book	(	CSTR	full,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)	,
		DBINS(z)
	)			`[inline, virtual]`

Book histogram and register it with the histogram data store.

Parameters:

	full	Full path to the node of the object. The basename (last part of the full) has to be an integer number (otherwise conversion to HBOOK is not possible)
	par	Path to parent node of the object, the directory the histogram will be stored in.
	pPar	Pointer to parent node
	rel	Histogram identifier (std::string), the relative path to the object with respect to the parent node
	hID	Histogram identifier (int) of the histogram
	title	Title property of the histogram
	DBINS(x/y/z)	Macro for bin definition in X/Y/Z. Expands to: int nx: Number of bins on the axis X/Y/Z double lx: Lower histogram edge on the axis X/Y/Z double ux: Upper histogram edge on the axis X/Y/Z

Definition at line 492 of file HistogramSvc.h.

00493   { return book(i_splitPath(full),title,BINS(x),BINS(y),BINS(z));            }

virtual H3D* HistogramSvc::book	(	CSTR	par,
		CSTR	rel,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)	,
		DBINS(z)
	)			`[inline, virtual]`

Definition at line 494 of file HistogramSvc.h.

00495   { return book(createPath(par),rel,title,BINS(x),BINS(y),BINS(z));          }

virtual H3D* HistogramSvc::book	(	CSTR	par,
		int	hID,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)	,
		DBINS(z)
	)			`[inline, virtual]`

Definition at line 496 of file HistogramSvc.h.

00497   { return book(par,_STR(hID),title,BINS(x),BINS(y),BINS(z));                }

virtual H3D* HistogramSvc::book	(	DataObject *	pPar,
		int	hID,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)	,
		DBINS(z)
	)			`[inline, virtual]`

Definition at line 498 of file HistogramSvc.h.

00499   { return book(pPar,_STR(hID), title, BINS(x),BINS(y),BINS(z));             }

virtual H3D* HistogramSvc::book	(	STRPAIR	loc,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)	,
		DBINS(z)
	)			`[inline, virtual]`

Definition at line 500 of file HistogramSvc.h.

00501   { return book(loc.first, loc.second, title, BINS(x),BINS(y),BINS(z));      }

virtual H3D* HistogramSvc::book	(	DataObject *	pPar,
		CSTR	rel,
		CSTR	title,
		DBINS(x)	,
		DBINS(y)	,
		DBINS(z)
	)			`[inline, virtual]`

Definition at line 502 of file HistogramSvc.h.

00503   { return i_book(pPar, rel, title, Gaudi::createH3D(title,BINS(x),BINS(y),BINS(z)));}

virtual H3D* HistogramSvc::book	(	CSTR	full,
		CSTR	title,
		Edges	x,
		Edges	y,
		Edges	z
	)			`[inline, virtual]`

Book histogram and register it with the histogram data store.

Parameters:

	full	Full path to the node of the object. The basename (last part of the full) has to be an integer number (otherwise conversion to HBOOK is not possible)
	par	Path to parent node of the object, the directory the histogram will be stored in.
	pPar	Pointer to parent node
	rel	Histogram identifier (std::string), the relative path to the object with respect to the parent node
	hID	Histogram identifier (int) of the histogram
	title	Title property of the histogram
	binsX/Y/Z	Number of bins on the axis X/Y/Z
	lowX/Y/Z	Lower histogram edge on the axis X/Y/Z
	highX/Y/Z	Upper histogram edge on the axis X/Y/Z

Definition at line 523 of file HistogramSvc.h.

00524   { return book(i_splitPath(full), title, x, y, z);                         }

virtual H3D* HistogramSvc::book	(	CSTR	par,
		CSTR	rel,
		CSTR	title,
		Edges	x,
		Edges	y,
		Edges	z
	)			`[inline, virtual]`

Definition at line 525 of file HistogramSvc.h.

00526   { return book(createPath(par), rel, title, x, y, z);                      }

virtual H3D* HistogramSvc::book	(	CSTR	par,
		int	hID,
		CSTR	title,
		Edges	x,
		Edges	y,
		Edges	z
	)			`[inline, virtual]`

Definition at line 527 of file HistogramSvc.h.

00528   { return book(par,_STR(hID), title, x, y, z);                             }

virtual H3D* HistogramSvc::book	(	DataObject *	pPar,
		int	hID,
		CSTR	title,
		Edges	x,
		Edges	y,
		Edges	z
	)			`[inline, virtual]`

Definition at line 529 of file HistogramSvc.h.

00530   { return book(pPar,_STR(hID), title, x, y, z);                            }

virtual H3D* HistogramSvc::book	(	STRPAIR	loc,
		CSTR	title,
		Edges	x,
		Edges	y,
		Edges	z
	)			`[inline, virtual]`

Definition at line 531 of file HistogramSvc.h.

00532   { return book(loc.first, loc.second, title, x,y,z);                       }

virtual H3D* HistogramSvc::book	(	DataObject *	pPar,
		CSTR	rel,
		CSTR	title,
		Edges	x,
		Edges	y,
		Edges	z
	)			`[inline, virtual]`

Definition at line 533 of file HistogramSvc.h.

00534   { return i_book(pPar, rel, title, Gaudi::createH3D(title,x,y,z));         }

virtual StatusCode HistogramSvc::registerObject	(	CSTR	parent,
		CSTR	rel,
		Base *	obj
	)			`[inline, virtual]`

Definition at line 542 of file HistogramSvc.h.

00543   { return registerObject(createPath(parent), rel, obj);                       }

virtual StatusCode HistogramSvc::registerObject	(	CSTR	parent,
		int	item,
		Base *	obj
	)			`[inline, virtual]`

Definition at line 544 of file HistogramSvc.h.

00545   { return registerObject(parent, _STR(item), obj);                            }

virtual StatusCode HistogramSvc::registerObject	(	Base *	pPar,
		CSTR	rel,
		Base *	obj
	)			`[inline, virtual]`

Definition at line 546 of file HistogramSvc.h.

00547   { return registerObject(__cast(pPar), rel, obj);                             }

virtual StatusCode HistogramSvc::registerObject	(	DataObject *	pPar,
		int	item,
		Base *	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 548 of file HistogramSvc.h.

00549   { return registerObject(pPar, _STR(item), obj);                              }

virtual StatusCode HistogramSvc::registerObject	(	Base *	pPar,
		int	item,
		Base *	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 550 of file HistogramSvc.h.

00551   { return registerObject(__cast(pPar), item, obj);                            }

virtual StatusCode HistogramSvc::registerObject	(	CSTR	full,
		Base *	obj
	)			`[virtual]`

virtual StatusCode HistogramSvc::registerObject	(	DataObject *	pPar,
		CSTR	rel,
		Base *	obj
	)			`[virtual]`

virtual StatusCode HistogramSvc::unregisterObject ( Base * obj ) [inline, virtual]

Implements IHistogramSvc.

Definition at line 557 of file HistogramSvc.h.

00558   { return DataSvc::unregisterObject(__cast(obj));                             }

virtual StatusCode HistogramSvc::unregisterObject	(	Base *	obj,
		CSTR	objectPath
	)			`[inline, virtual]`

Definition at line 559 of file HistogramSvc.h.

00560   { return DataSvc::unregisterObject(__cast(obj),objectPath);                  }

virtual StatusCode HistogramSvc::unregisterObject	(	Base *	obj,
		int	item
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 561 of file HistogramSvc.h.

00562   { return DataSvc::unregisterObject(__cast(obj),item);                        }

virtual StatusCode HistogramSvc::retrieveObject	(	IRegistry *	pReg,
		CSTR	path,
		H1D *&	obj
	)			`[inline, virtual]`

Definition at line 566 of file HistogramSvc.h.

00567   { return Helper(this).retrieve(pReg,path,obj);                                }

virtual StatusCode HistogramSvc::retrieveObject	(	IRegistry *	pReg,
		CSTR	path,
		P1D *&	obj
	)			`[inline, virtual]`

Definition at line 568 of file HistogramSvc.h.

00569   { return Helper(this).retrieve(pReg,path,obj);                                }

virtual StatusCode HistogramSvc::retrieveObject	(	IRegistry *	pReg,
		CSTR	path,
		H2D *&	obj
	)			`[inline, virtual]`

Definition at line 570 of file HistogramSvc.h.

00571   { return Helper(this).retrieve(pReg,path,obj);                                }

virtual StatusCode HistogramSvc::retrieveObject	(	IRegistry *	pReg,
		CSTR	path,
		P2D *&	obj
	)			`[inline, virtual]`

Definition at line 572 of file HistogramSvc.h.

00573   { return Helper(this).retrieve(pReg,path,obj);                                }

virtual StatusCode HistogramSvc::retrieveObject	(	IRegistry *	pReg,
		CSTR	path,
		H3D *&	obj
	)			`[inline, virtual]`

Definition at line 574 of file HistogramSvc.h.

00575   { return Helper(this).retrieve(pReg,path,obj);                                }

virtual StatusCode HistogramSvc::retrieveObject	(	CSTR	full,
		P1D *&	obj
	)			`[inline, virtual]`

Definition at line 577 of file HistogramSvc.h.

00578   {  return Helper(this).retrieve(full,obj);                                    }

virtual StatusCode HistogramSvc::retrieveObject	(	CSTR	full,
		P2D *&	obj
	)			`[inline, virtual]`

Definition at line 579 of file HistogramSvc.h.

00580   {  return Helper(this).retrieve(full,obj);                                    }

virtual StatusCode HistogramSvc::retrieveObject	(	CSTR	full,
		H1D *&	obj
	)			`[inline, virtual]`

Definition at line 581 of file HistogramSvc.h.

00582   {  return Helper(this).retrieve(full,obj);                                    }

virtual StatusCode HistogramSvc::retrieveObject	(	CSTR	full,
		H2D *&	obj
	)			`[inline, virtual]`

Definition at line 583 of file HistogramSvc.h.

00584   {  return Helper(this).retrieve(full,obj);                                    }

virtual StatusCode HistogramSvc::retrieveObject	(	CSTR	full,
		H3D *&	obj
	)			`[inline, virtual]`

Definition at line 585 of file HistogramSvc.h.

00586   {  return Helper(this).retrieve(full,obj);                                    }

virtual StatusCode HistogramSvc::retrieveObject	(	CSTR	parent,
		CSTR	rel,
		P1D *&	obj
	)			`[inline, virtual]`

Definition at line 588 of file HistogramSvc.h.

00589   {  return Helper(this).retrieve(parent,rel,obj);                              }

virtual StatusCode HistogramSvc::retrieveObject	(	CSTR	parent,
		CSTR	rel,
		P2D *&	obj
	)			`[inline, virtual]`

Definition at line 590 of file HistogramSvc.h.

00591   {  return Helper(this).retrieve(parent,rel,obj);                              }

virtual StatusCode HistogramSvc::retrieveObject	(	CSTR	parent,
		CSTR	rel,
		H1D *&	obj
	)			`[inline, virtual]`

Definition at line 592 of file HistogramSvc.h.

00593   {  return Helper(this).retrieve(parent,rel,obj);                              }

virtual StatusCode HistogramSvc::retrieveObject	(	CSTR	parent,
		CSTR	rel,
		H2D *&	obj
	)			`[inline, virtual]`

Definition at line 594 of file HistogramSvc.h.

00595   {  return Helper(this).retrieve(parent,rel,obj);                              }

virtual StatusCode HistogramSvc::retrieveObject	(	CSTR	parent,
		CSTR	rel,
		H3D *&	obj
	)			`[inline, virtual]`

Definition at line 596 of file HistogramSvc.h.

00597   {  return Helper(this).retrieve(parent,rel,obj);                              }

virtual StatusCode HistogramSvc::retrieveObject	(	CSTR	parent,
		int	item,
		P1D *&	obj
	)			`[inline, virtual]`

Definition at line 599 of file HistogramSvc.h.

00600   {  return Helper(this).retrieve(parent,item,obj);                             }

virtual StatusCode HistogramSvc::retrieveObject	(	CSTR	parent,
		int	item,
		P2D *&	obj
	)			`[inline, virtual]`

Definition at line 601 of file HistogramSvc.h.

00602   {  return Helper(this).retrieve(parent,item,obj);                             }

virtual StatusCode HistogramSvc::retrieveObject	(	CSTR	parent,
		int	item,
		H1D *&	obj
	)			`[inline, virtual]`

Definition at line 603 of file HistogramSvc.h.

00604   {  return Helper(this).retrieve(parent,item,obj);                             }

virtual StatusCode HistogramSvc::retrieveObject	(	CSTR	parent,
		int	item,
		H2D *&	obj
	)			`[inline, virtual]`

Definition at line 605 of file HistogramSvc.h.

00606   {  return Helper(this).retrieve(parent,item,obj);                             }

virtual StatusCode HistogramSvc::retrieveObject	(	CSTR	parent,
		int	item,
		H3D *&	obj
	)			`[inline, virtual]`

Definition at line 607 of file HistogramSvc.h.

00608   {  return Helper(this).retrieve(parent,item,obj);                             }

virtual StatusCode HistogramSvc::retrieveObject	(	DataObject *	par,
		CSTR	item,
		P1D *&	obj
	)			`[inline, virtual]`

Definition at line 610 of file HistogramSvc.h.

00611   {  return Helper(this).retrieve(par,item,obj);                                }

virtual StatusCode HistogramSvc::retrieveObject	(	DataObject *	par,
		CSTR	item,
		P2D *&	obj
	)			`[inline, virtual]`

Definition at line 612 of file HistogramSvc.h.

00613   {  return Helper(this).retrieve(par,item,obj);                                }

virtual StatusCode HistogramSvc::retrieveObject	(	DataObject *	par,
		CSTR	item,
		H1D *&	obj
	)			`[inline, virtual]`

Definition at line 614 of file HistogramSvc.h.

00615   {  return Helper(this).retrieve(par,item,obj);                                }

virtual StatusCode HistogramSvc::retrieveObject	(	DataObject *	par,
		CSTR	item,
		H2D *&	obj
	)			`[inline, virtual]`

Definition at line 616 of file HistogramSvc.h.

00617   {  return Helper(this).retrieve(par,item,obj);                                }

virtual StatusCode HistogramSvc::retrieveObject	(	DataObject *	par,
		CSTR	item,
		H3D *&	obj
	)			`[inline, virtual]`

Definition at line 618 of file HistogramSvc.h.

00619   {  return Helper(this).retrieve(par,item,obj);                                }

virtual StatusCode HistogramSvc::retrieveObject	(	DataObject *	par,
		int	item,
		P1D *&	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 621 of file HistogramSvc.h.

00622   {  return Helper(this).retrieve(par,item,obj);                                }

virtual StatusCode HistogramSvc::retrieveObject	(	DataObject *	par,
		int	item,
		P2D *&	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 623 of file HistogramSvc.h.

00624   {  return Helper(this).retrieve(par,item,obj);                                }

virtual StatusCode HistogramSvc::retrieveObject	(	DataObject *	par,
		int	item,
		H1D *&	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 625 of file HistogramSvc.h.

00626   {  return Helper(this).retrieve(par,item,obj);                                }

virtual StatusCode HistogramSvc::retrieveObject	(	DataObject *	par,
		int	item,
		H2D *&	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 627 of file HistogramSvc.h.

00628   {  return Helper(this).retrieve(par,item,obj);                                }

virtual StatusCode HistogramSvc::retrieveObject	(	DataObject *	par,
		int	item,
		H3D *&	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 629 of file HistogramSvc.h.

00630   {  return Helper(this).retrieve(par,item,obj);                                }

virtual StatusCode HistogramSvc::retrieveObject	(	Base *	par,
		int	item,
		P1D *&	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 632 of file HistogramSvc.h.

00633   {  return Helper(this).retrieve(__cast(par),item,obj);                        }

virtual StatusCode HistogramSvc::retrieveObject	(	Base *	par,
		int	item,
		P2D *&	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 634 of file HistogramSvc.h.

00635   {  return Helper(this).retrieve(__cast(par),item,obj);                        }

virtual StatusCode HistogramSvc::retrieveObject	(	Base *	par,
		int	item,
		H1D *&	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 636 of file HistogramSvc.h.

00637   {  return Helper(this).retrieve(__cast(par),item,obj);                        }

virtual StatusCode HistogramSvc::retrieveObject	(	Base *	par,
		int	item,
		H2D *&	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 638 of file HistogramSvc.h.

00639   {  return Helper(this).retrieve(__cast(par),item,obj);                        }

virtual StatusCode HistogramSvc::retrieveObject	(	Base *	par,
		int	item,
		H3D *&	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 640 of file HistogramSvc.h.

00641   {  return Helper(this).retrieve(__cast(par),item,obj);                        }

virtual StatusCode HistogramSvc::retrieveObject	(	Base *	par,
		CSTR	item,
		P1D *&	obj
	)			`[inline, virtual]`

Definition at line 643 of file HistogramSvc.h.

00644   {  return Helper(this).retrieve(__cast(par),item,obj);                        }

virtual StatusCode HistogramSvc::retrieveObject	(	Base *	par,
		CSTR	item,
		P2D *&	obj
	)			`[inline, virtual]`

Definition at line 645 of file HistogramSvc.h.

00646   {  return Helper(this).retrieve(__cast(par),item,obj);                        }

virtual StatusCode HistogramSvc::retrieveObject	(	Base *	par,
		CSTR	item,
		H1D *&	obj
	)			`[inline, virtual]`

Definition at line 647 of file HistogramSvc.h.

00648   {  return Helper(this).retrieve(__cast(par),item,obj);                        }

virtual StatusCode HistogramSvc::retrieveObject	(	Base *	par,
		CSTR	item,
		H2D *&	obj
	)			`[inline, virtual]`

Definition at line 649 of file HistogramSvc.h.

00650   {  return Helper(this).retrieve(__cast(par),item,obj);                        }

virtual StatusCode HistogramSvc::retrieveObject	(	Base *	par,
		CSTR	item,
		H3D *&	obj
	)			`[inline, virtual]`

Definition at line 651 of file HistogramSvc.h.

00652   {  return Helper(this).retrieve(__cast(par),item,obj);                        }

virtual StatusCode HistogramSvc::findObject	(	IRegistry *	pReg,
		CSTR	path,
		P1D *&	obj
	)			`[inline, virtual]`

Definition at line 661 of file HistogramSvc.h.

00662   {  return Helper(this).find(pReg,path,obj);                                 }

virtual StatusCode HistogramSvc::findObject	(	IRegistry *	pReg,
		CSTR	path,
		P2D *&	obj
	)			`[inline, virtual]`

Definition at line 663 of file HistogramSvc.h.

00664   {  return Helper(this).find(pReg,path,obj);                                 }

virtual StatusCode HistogramSvc::findObject	(	IRegistry *	pReg,
		CSTR	path,
		H1D *&	obj
	)			`[inline, virtual]`

Definition at line 665 of file HistogramSvc.h.

00666   {  return Helper(this).find(pReg,path,obj);                                 }

virtual StatusCode HistogramSvc::findObject	(	IRegistry *	pReg,
		CSTR	path,
		H2D *&	obj
	)			`[inline, virtual]`

Definition at line 667 of file HistogramSvc.h.

00668   {  return Helper(this).find(pReg,path,obj);                                 }

virtual StatusCode HistogramSvc::findObject	(	IRegistry *	pReg,
		CSTR	path,
		H3D *&	obj
	)			`[inline, virtual]`

Definition at line 669 of file HistogramSvc.h.

00670   {  return Helper(this).find(pReg,path,obj);                                 }

virtual StatusCode HistogramSvc::findObject	(	CSTR	full,
		P1D *&	obj
	)			`[inline, virtual]`

Definition at line 672 of file HistogramSvc.h.

00673   {  return Helper(this).find(full,obj);                                      }

virtual StatusCode HistogramSvc::findObject	(	CSTR	full,
		P2D *&	obj
	)			`[inline, virtual]`

Definition at line 674 of file HistogramSvc.h.

00675   {  return Helper(this).find(full,obj);                                      }

virtual StatusCode HistogramSvc::findObject	(	CSTR	full,
		H1D *&	obj
	)			`[inline, virtual]`

Definition at line 676 of file HistogramSvc.h.

00677   {  return Helper(this).find(full,obj);                                      }

virtual StatusCode HistogramSvc::findObject	(	CSTR	full,
		H2D *&	obj
	)			`[inline, virtual]`

Definition at line 678 of file HistogramSvc.h.

00679   {  return Helper(this).find(full,obj);                                      }

virtual StatusCode HistogramSvc::findObject	(	CSTR	full,
		H3D *&	obj
	)			`[inline, virtual]`

Definition at line 680 of file HistogramSvc.h.

00681   {  return Helper(this).find(full,obj);                                      }

virtual StatusCode HistogramSvc::findObject	(	CSTR	par,
		CSTR	rel,
		P1D *&	obj
	)			`[inline, virtual]`

Definition at line 683 of file HistogramSvc.h.

00684   {  return Helper(this).find(par,rel,obj);                                   }

virtual StatusCode HistogramSvc::findObject	(	CSTR	par,
		CSTR	rel,
		P2D *&	obj
	)			`[inline, virtual]`

Definition at line 685 of file HistogramSvc.h.

00686   {  return Helper(this).find(par,rel,obj);                                   }

virtual StatusCode HistogramSvc::findObject	(	CSTR	par,
		CSTR	rel,
		H1D *&	obj
	)			`[inline, virtual]`

Definition at line 687 of file HistogramSvc.h.

00688   {  return Helper(this).find(par,rel,obj);                                   }

virtual StatusCode HistogramSvc::findObject	(	CSTR	par,
		CSTR	rel,
		H2D *&	obj
	)			`[inline, virtual]`

Definition at line 689 of file HistogramSvc.h.

00690   {  return Helper(this).find(par,rel,obj);                                   }

virtual StatusCode HistogramSvc::findObject	(	CSTR	par,
		CSTR	rel,
		H3D *&	obj
	)			`[inline, virtual]`

Definition at line 691 of file HistogramSvc.h.

00692   {  return Helper(this).find(par,rel,obj);                                   }

virtual StatusCode HistogramSvc::findObject	(	CSTR	par,
		int	item,
		P1D *&	obj
	)			`[inline, virtual]`

Definition at line 694 of file HistogramSvc.h.

00695   {  return Helper(this).find(par,item,obj);                                  }

virtual StatusCode HistogramSvc::findObject	(	CSTR	par,
		int	item,
		P2D *&	obj
	)			`[inline, virtual]`

Definition at line 696 of file HistogramSvc.h.

00697   {  return Helper(this).find(par,item,obj);                                  }

virtual StatusCode HistogramSvc::findObject	(	CSTR	par,
		int	item,
		H1D *&	obj
	)			`[inline, virtual]`

Definition at line 698 of file HistogramSvc.h.

00699   {  return Helper(this).find(par,item,obj);                                  }

virtual StatusCode HistogramSvc::findObject	(	CSTR	par,
		int	item,
		H2D *&	obj
	)			`[inline, virtual]`

Definition at line 700 of file HistogramSvc.h.

00701   {  return Helper(this).find(par,item,obj);                                  }

virtual StatusCode HistogramSvc::findObject	(	CSTR	par,
		int	item,
		H3D *&	obj
	)			`[inline, virtual]`

Definition at line 702 of file HistogramSvc.h.

00703   {  return Helper(this).find(par,item,obj);                                  }

virtual StatusCode HistogramSvc::findObject	(	DataObject *	par,
		int	item,
		P1D *&	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 705 of file HistogramSvc.h.

00706   {  return Helper(this).find(par,item,obj);                                  }

virtual StatusCode HistogramSvc::findObject	(	DataObject *	par,
		int	item,
		P2D *&	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 707 of file HistogramSvc.h.

00708   {  return Helper(this).find(par,item,obj);                                  }

virtual StatusCode HistogramSvc::findObject	(	DataObject *	par,
		int	item,
		H1D *&	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 709 of file HistogramSvc.h.

00710   {  return Helper(this).find(par,item,obj);                                  }

virtual StatusCode HistogramSvc::findObject	(	DataObject *	par,
		int	item,
		H2D *&	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 711 of file HistogramSvc.h.

00712   {  return Helper(this).find(par,item,obj);                                  }

virtual StatusCode HistogramSvc::findObject	(	DataObject *	par,
		int	item,
		H3D *&	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 713 of file HistogramSvc.h.

00714   {  return Helper(this).find(par,item,obj);                                  }

virtual StatusCode HistogramSvc::findObject	(	DataObject *	par,
		CSTR	item,
		P1D *&	obj
	)			`[inline, virtual]`

Definition at line 716 of file HistogramSvc.h.

00717   {  return Helper(this).find(par,item,obj);                                  }

virtual StatusCode HistogramSvc::findObject	(	DataObject *	par,
		CSTR	item,
		P2D *&	obj
	)			`[inline, virtual]`

Definition at line 718 of file HistogramSvc.h.

00719   {  return Helper(this).find(par,item,obj);                                  }

virtual StatusCode HistogramSvc::findObject	(	DataObject *	par,
		CSTR	item,
		H1D *&	obj
	)			`[inline, virtual]`

Definition at line 720 of file HistogramSvc.h.

00721   {  return Helper(this).find(par,item,obj);                                  }

virtual StatusCode HistogramSvc::findObject	(	DataObject *	par,
		CSTR	item,
		H2D *&	obj
	)			`[inline, virtual]`

Definition at line 722 of file HistogramSvc.h.

00723   {  return Helper(this).find(par,item,obj);                                  }

virtual StatusCode HistogramSvc::findObject	(	DataObject *	par,
		CSTR	item,
		H3D *&	obj
	)			`[inline, virtual]`

Definition at line 724 of file HistogramSvc.h.

00725   {  return Helper(this).find(par,item,obj);                                  }

virtual StatusCode HistogramSvc::findObject	(	Base *	par,
		int	item,
		P1D *&	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 727 of file HistogramSvc.h.

00728   {  return Helper(this).find(__cast(par),item,obj);                          }

virtual StatusCode HistogramSvc::findObject	(	Base *	par,
		int	item,
		P2D *&	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 729 of file HistogramSvc.h.

00730   {  return Helper(this).find(__cast(par),item,obj);                          }

virtual StatusCode HistogramSvc::findObject	(	Base *	par,
		int	item,
		H1D *&	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 731 of file HistogramSvc.h.

00732   {  return Helper(this).find(__cast(par),item,obj);                          }

virtual StatusCode HistogramSvc::findObject	(	Base *	par,
		int	item,
		H2D *&	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 733 of file HistogramSvc.h.

00734   {  return Helper(this).find(__cast(par),item,obj);                          }

virtual StatusCode HistogramSvc::findObject	(	Base *	par,
		int	item,
		H3D *&	obj
	)			`[inline, virtual]`

Implements IHistogramSvc.

Definition at line 735 of file HistogramSvc.h.

00736   {  return Helper(this).find(__cast(par),item,obj);                          }

virtual StatusCode HistogramSvc::findObject	(	Base *	par,
		CSTR	item,
		P1D *&	obj
	)			`[inline, virtual]`

Definition at line 738 of file HistogramSvc.h.

00739   {  return Helper(this).find(__cast(par),item,obj);                          }

virtual StatusCode HistogramSvc::findObject	(	Base *	par,
		CSTR	item,
		P2D *&	obj
	)			`[inline, virtual]`

Definition at line 740 of file HistogramSvc.h.

00741   {  return Helper(this).find(__cast(par),item,obj);                          }

virtual StatusCode HistogramSvc::findObject	(	Base *	par,
		CSTR	item,
		H1D *&	obj
	)			`[inline, virtual]`

Definition at line 742 of file HistogramSvc.h.

00743   {  return Helper(this).find(__cast(par),item,obj);                          }

virtual StatusCode HistogramSvc::findObject	(	Base *	par,
		CSTR	item,
		H2D *&	obj
	)			`[inline, virtual]`

Definition at line 744 of file HistogramSvc.h.

00745   {  return Helper(this).find(__cast(par),item,obj);                          }

virtual StatusCode HistogramSvc::findObject	(	Base *	par,
		CSTR	item,
		H3D *&	obj
	)			`[inline, virtual]`

Definition at line 746 of file HistogramSvc.h.

00747   {  return Helper(this).find(__cast(par),item,obj);                          }

virtual H1D* HistogramSvc::projectionX	(	CSTR	name,
		const H2D &	h
	)			`[inline, virtual]`

Definition at line 752 of file HistogramSvc.h.

00753   {  return sliceX( name, h, IAxis::UNDERFLOW_BIN, IAxis::OVERFLOW_BIN);      }

virtual H1D* HistogramSvc::projectionY	(	CSTR	name,
		const H2D &	h
	)			`[inline, virtual]`

Definition at line 754 of file HistogramSvc.h.

00755   {  return sliceY( name, h, IAxis::UNDERFLOW_BIN, IAxis::OVERFLOW_BIN);      }

virtual H1D* HistogramSvc::sliceX	(	CSTR	name,
		const H2D &	h,
		int	indexY
	)			`[inline, virtual]`

Definition at line 756 of file HistogramSvc.h.

00757   {  return sliceX( name, h, indexY, indexY );                                }

virtual H1D* HistogramSvc::sliceY	(	CSTR	name,
		const H2D &	h,
		int	indexX
	)			`[inline, virtual]`

Definition at line 758 of file HistogramSvc.h.

00759   {  return sliceY( name, h, indexX, indexX );                                }

virtual H1D* HistogramSvc::sliceX	(	CSTR	name,
		const H2D &	h,
		int	indexY1,
		int	indexY2
	)			`[virtual]`

virtual H1D* HistogramSvc::sliceY	(	CSTR	name,
		const H2D &	h,
		int	indexX1,
		int	indexX2
	)			`[virtual]`

bool HistogramSvc::destroy ( IBaseHistogram * hist )

Definition at line 351 of file HistogramSvc.cpp.

00351                                                  {
00352   StatusCode sc = unregisterObject( dynamic_cast<IHistogram*>(hist) );
00353   if ( !sc.isSuccess() ) return false;
00354   if ( hist ) delete hist;
00355   return true;
00356 }

H1D* HistogramSvc::add	(	CSTR	nameAndTitle,
		const H1D &	a,
		const H1D &	b
	)			`[inline]`

Definition at line 765 of file HistogramSvc.h.

00766   { return Helper::act(createCopy(nameAndTitle,a),b,&TH1::Add, 1.);          }

H1D* HistogramSvc::subtract	(	CSTR	nameAndTitle,
		const H1D &	a,
		const H1D &	b
	)			`[inline]`

Definition at line 767 of file HistogramSvc.h.

00768   { return Helper::act(createCopy(nameAndTitle,a),b,&TH1::Add,-1.);          }

H1D* HistogramSvc::multiply	(	CSTR	nameAndTitle,
		const H1D &	a,
		const H1D &	b
	)			`[inline]`

Definition at line 769 of file HistogramSvc.h.

00770   { return Helper::act(createCopy(nameAndTitle,a),b,&TH1::Multiply);         }

H1D* HistogramSvc::divide	(	CSTR	nameAndTitle,
		const H1D &	a,
		const H1D &	b
	)			`[inline]`

Definition at line 771 of file HistogramSvc.h.

00772   { return Helper::act(createCopy(nameAndTitle,a),b,&TH1::Divide);           }

H2D* HistogramSvc::add	(	CSTR	nameAndTitle,
		const H2D &	a,
		const H2D &	b
	)			`[inline]`

Definition at line 774 of file HistogramSvc.h.

00775   { return Helper::act(createCopy(nameAndTitle,a),b,&TH2D::Add, 1.);           }

H2D* HistogramSvc::subtract	(	CSTR	nameAndTitle,
		const H2D &	a,
		const H2D &	b
	)			`[inline]`

Definition at line 776 of file HistogramSvc.h.

00777   { return Helper::act(createCopy(nameAndTitle,a),b,&TH2D::Add,-1.);           }

H2D* HistogramSvc::multiply	(	CSTR	nameAndTitle,
		const H2D &	a,
		const H2D &	b
	)			`[inline]`

Definition at line 778 of file HistogramSvc.h.

00779   { return Helper::act(createCopy(nameAndTitle,a),b,&TH2D::Multiply);          }

H2D* HistogramSvc::divide	(	CSTR	nameAndTitle,
		const H2D &	a,
		const H2D &	b
	)			`[inline]`

Definition at line 780 of file HistogramSvc.h.

00781   { return Helper::act(createCopy(nameAndTitle,a),b,&TH2D::Divide);            }

H3D* HistogramSvc::add	(	CSTR	nameAndTitle,
		const H3D &	a,
		const H3D &	b
	)			`[inline]`

Definition at line 783 of file HistogramSvc.h.

00784   { return Helper::act(createCopy(nameAndTitle,a),b,&TH3D::Add, 1.);           }

H3D* HistogramSvc::subtract	(	CSTR	nameAndTitle,
		const H3D &	a,
		const H3D &	b
	)			`[inline]`

Definition at line 785 of file HistogramSvc.h.

00786   { return Helper::act(createCopy(nameAndTitle,a),b,&TH3D::Add,-1.);           }

H3D* HistogramSvc::multiply	(	CSTR	nameAndTitle,
		const H3D &	a,
		const H3D &	b
	)			`[inline]`

Definition at line 787 of file HistogramSvc.h.

00788   { return Helper::act(createCopy(nameAndTitle,a),b,&TH3D::Multiply);          }

H3D* HistogramSvc::divide	(	CSTR	nameAndTitle,
		const H3D &	a,
		const H3D &	b
	)			`[inline]`

Definition at line 789 of file HistogramSvc.h.

00790   { return Helper::act(createCopy(nameAndTitle,a),b,&TH3D::Divide);            }

H2D* HistogramSvc::projectionXY	(	CSTR	nameAndTitle,
		const H3D &	h
	)			`[inline]`

Definition at line 792 of file HistogramSvc.h.

00793   { return i_project(nameAndTitle,h,"xy");                                    }

H2D* HistogramSvc::projectionXZ	(	CSTR	nameAndTitle,
		const H3D &	h
	)			`[inline]`

Definition at line 794 of file HistogramSvc.h.

00795   { return i_project(nameAndTitle,h,"xz");                                    }

H2D* HistogramSvc::projectionYZ	(	CSTR	nameAndTitle,
		const H3D &	h
	)			`[inline]`

Definition at line 796 of file HistogramSvc.h.

00797   { return i_project(nameAndTitle,h,"yz");                                    }

H2D* HistogramSvc::sliceXY	(	CSTR	,
		const H3D &	,
		int	,
		int
	)

H2D* const H3D int NOT_IMPLEMENTED H2D* HistogramSvc::sliceYZ	(	CSTR	,
		const H3D &	,
		int	,
		int
	)

Type Constraints

H2D* const H3D int NOT_IMPLEMENTED H2D* CSTR HistogramSvc::DBINS ( x ) [inline]

Type Constraints

Definition at line 803 of file HistogramSvc.h.

00804   {  return book( name, tit, BINS(x));                                        }

H1D* HistogramSvc::createHistogram1D	(	CSTR	name,
		CSTR	tit,
		DBINS(x)	,
		CSTR
	)			`[inline]`

Definition at line 805 of file HistogramSvc.h.

00806   {  return book( name, tit, BINS(x));                                        }

H1D* HistogramSvc::createHistogram1D	(	CSTR	name,
		CSTR	title,
		const Edges &	x,
		CSTR
	)			`[inline]`

Definition at line 807 of file HistogramSvc.h.

00808   {  return book(name, title, x);                                             }

H1D* HistogramSvc::createHistogram1D	(	CSTR	nameAndTitle,
		DBINS(x)
	)			`[inline]`

Definition at line 809 of file HistogramSvc.h.

00810   { return book(nameAndTitle, nameAndTitle, BINS(x));                         }

H1D* HistogramSvc::createCopy	(	CSTR	full,
		const H1D &	h
	)			`[inline]`

Definition at line 811 of file HistogramSvc.h.

00812   {  return createCopy(i_splitPath(full), h);                                 }

H1D* HistogramSvc::createCopy	(	CSTR	par,
		CSTR	rel,
		const H1D &	h
	)			`[inline]`

Definition at line 813 of file HistogramSvc.h.

00814   {  return createCopy(createPath(par), rel, h);                              }

H1D* HistogramSvc::createCopy	(	STRPAIR	loc,
		const H1D &	h
	)			`[inline]`

Definition at line 815 of file HistogramSvc.h.

00816   {  return createCopy(loc.first, loc.second, h);                             }

H1D* HistogramSvc::createCopy	(	DataObject *	pPar,
		CSTR	rel,
		const H1D &	h
	)			`[inline]`

Definition at line 817 of file HistogramSvc.h.

00818   { return i_book(pPar, rel, h.title(), Gaudi::createH1D(h));                 }

H2D* HistogramSvc::createHistogram2D	(	CSTR	name,
		CSTR	tit,
		DBINS(x)	,
		DBINS(y)
	)			`[inline]`

Definition at line 820 of file HistogramSvc.h.

00821   {  return book( name, tit, BINS(x), BINS(y));                               }

H2D* HistogramSvc::createHistogram2D	(	CSTR	name,
		CSTR	tit,
		DBINS(x)	,
		DBINS(y)	,
		CSTR
	)			`[inline]`

Definition at line 822 of file HistogramSvc.h.

00823   {  return book( name, tit, BINS(x), BINS(y));                               }

H2D* HistogramSvc::createHistogram2D	(	CSTR	name,
		CSTR	title,
		const Edges &	x,
		const Edges &	y,
		CSTR
	)			`[inline]`

Definition at line 824 of file HistogramSvc.h.

00825   {  return book(name, title, x, y);                                          }

H2D* HistogramSvc::createHistogram2D	(	CSTR	nameAndTitle,
		DBINS(x)	,
		DBINS(y)
	)			`[inline]`

Definition at line 826 of file HistogramSvc.h.

00827   { return book(nameAndTitle, nameAndTitle, BINS(x), BINS(y));                }

H2D* HistogramSvc::createCopy	(	CSTR	full,
		const H2D &	h
	)			`[inline]`

Definition at line 828 of file HistogramSvc.h.

00829   {  return createCopy(i_splitPath(full), h);                                 }

H2D* HistogramSvc::createCopy	(	CSTR	par,
		CSTR	rel,
		const H2D &	h
	)			`[inline]`

Definition at line 830 of file HistogramSvc.h.

00831   {  return createCopy(createPath(par), rel, h);                              }

H2D* HistogramSvc::createCopy	(	STRPAIR	loc,
		const H2D &	h
	)			`[inline]`

Definition at line 832 of file HistogramSvc.h.

00833   {  return createCopy(loc.first, loc.second, h);                             }

H2D* HistogramSvc::createCopy	(	DataObject *	pPar,
		CSTR	rel,
		const H2D &	h
	)			`[inline]`

Definition at line 834 of file HistogramSvc.h.

00835   { return i_book(pPar, rel, h.title(), Gaudi::createH2D(h));                 }

H3D* HistogramSvc::createHistogram3D	(	CSTR	name,
		CSTR	tit,
		DBINS(x)	,
		DBINS(y)	,
		DBINS(z)
	)			`[inline]`

Definition at line 837 of file HistogramSvc.h.

00838   {  return book( name, tit, BINS(x), BINS(y), BINS(z));                      }

H3D* HistogramSvc::createHistogram3D	(	CSTR	name,
		CSTR	tit,
		DBINS(x)	,
		DBINS(y)	,
		DBINS(z)	,
		CSTR
	)			`[inline]`

Definition at line 839 of file HistogramSvc.h.

00840   {  return book( name, tit, BINS(x), BINS(y), BINS(z));                      }

H3D* HistogramSvc::createHistogram3D	(	CSTR	name,
		CSTR	title,
		const Edges &	x,
		const Edges &	y,
		const Edges &	z,
		CSTR
	)			`[inline]`

Definition at line 841 of file HistogramSvc.h.

00842   {  return book(name, title, x, y, z);                                       }

H3D* HistogramSvc::createHistogram3D	(	CSTR	nameAndTitle,
		DBINS(x)	,
		DBINS(y)	,
		DBINS(z)
	)			`[inline]`

Definition at line 843 of file HistogramSvc.h.

00844   { return book(nameAndTitle, nameAndTitle, BINS(x), BINS(y), BINS(z));       }

H3D* HistogramSvc::createCopy	(	CSTR	full,
		const H3D &	h
	)			`[inline]`

Definition at line 845 of file HistogramSvc.h.

00846   {  return createCopy(i_splitPath(full), h);                                 }

H3D* HistogramSvc::createCopy	(	CSTR	par,
		CSTR	rel,
		const H3D &	h
	)			`[inline]`

Definition at line 847 of file HistogramSvc.h.

00848   {  return createCopy(createPath(par), rel, h);                              }

H3D* HistogramSvc::createCopy	(	STRPAIR	loc,
		const H3D &	h
	)			`[inline]`

Definition at line 849 of file HistogramSvc.h.

00850   {  return createCopy(loc.first, loc.second, h);                             }

H3D* HistogramSvc::createCopy	(	DataObject *	pPar,
		CSTR	rel,
		const H3D &	h
	)			`[inline]`

Definition at line 851 of file HistogramSvc.h.

00852   { return i_book(pPar, rel, h.title(), Gaudi::createH3D(h));                 }

P1D* HistogramSvc::createProfile1D	(	CSTR	name,
		CSTR	tit,
		DBINS(x)	,
		CSTR	opt
	)			`[inline]`

Definition at line 856 of file HistogramSvc.h.

00857   {  return bookProf( name, tit, BINS(x) , opt );                             }

P1D* HistogramSvc::createProfile1D	(	CSTR	name,
		CSTR	tit,
		DBINS(x)	,
		double	upper,
		double	lower,
		CSTR	opt
	)			`[inline]`

Definition at line 858 of file HistogramSvc.h.

00859   {  return bookProf( name, tit, BINS(x), upper, lower , opt );               }

P1D* HistogramSvc::createProfile1D	(	CSTR	name,
		CSTR	title,
		const Edges &	x,
		CSTR
	)			`[inline]`

Definition at line 860 of file HistogramSvc.h.

00861   {  return bookProf(name, title, x );                                        }

P1D* HistogramSvc::createProfile1D	(	CSTR	name,
		CSTR	title,
		const Edges &	x,
		double	upper,
		double	lower,
		CSTR
	)			`[inline]`

Definition at line 862 of file HistogramSvc.h.

00863   {  return bookProf(name, title, x, upper, lower );                          }

P1D* HistogramSvc::createProfile1D	(	CSTR	nametit,
		DBINS(x)
	)			`[inline]`

Definition at line 865 of file HistogramSvc.h.

00866   {  return bookProf( nametit, nametit, BINS(x) , "s");                       }

P1D* HistogramSvc::createProfile1D	(	CSTR	nametit,
		DBINS(x)	,
		double	upper,
		double	lower
	)			`[inline]`

Definition at line 867 of file HistogramSvc.h.

00868   {  return bookProf( nametit, nametit, BINS(x), upper, lower , "s");         }

P1D* HistogramSvc::createCopy	(	CSTR	full,
		const P1D &	h
	)			`[inline]`

Definition at line 871 of file HistogramSvc.h.

00872   {  return createCopy(i_splitPath(full), h);                                 }

P1D* HistogramSvc::createCopy	(	CSTR	par,
		CSTR	rel,
		const P1D &	h
	)			`[inline]`

Definition at line 873 of file HistogramSvc.h.

00874   {  return createCopy(createPath(par), rel, h);                              }

P1D* HistogramSvc::createCopy	(	STRPAIR	loc,
		const P1D &	h
	)			`[inline]`

Definition at line 875 of file HistogramSvc.h.

00876   {  return createCopy(loc.first, loc.second, h);                             }

P1D* HistogramSvc::createCopy	(	DataObject *	pPar,
		CSTR	rel,
		const P1D &	h
	)			`[inline]`

Definition at line 877 of file HistogramSvc.h.

00878   { return i_book(pPar, rel, h.title(), Gaudi::createProf1D(h));              }

P2D* HistogramSvc::createProfile2D	(	CSTR	name,
		CSTR	tit,
		DBINS(x)	,
		DBINS(y)
	)			`[inline]`

Definition at line 880 of file HistogramSvc.h.

00881   {  return bookProf( name, tit, BINS(x), BINS(y));                           }

P2D* HistogramSvc::createProfile2D	(	CSTR	name,
		CSTR	tit,
		DBINS(x)	,
		DBINS(y)	,
		CSTR
	)			`[inline]`

Definition at line 882 of file HistogramSvc.h.

00883   {  return bookProf( name, tit, BINS(x), BINS(y));                           }

P2D* HistogramSvc::createProfile2D	(	CSTR	name,
		CSTR	title,
		const Edges &	x,
		const Edges &	y,
		CSTR
	)			`[inline]`

Definition at line 884 of file HistogramSvc.h.

00885   {  return bookProf(name, title, x, y);                                      }

P2D* HistogramSvc::createProfile2D	(	CSTR	nameAndTitle,
		DBINS(x)	,
		DBINS(y)
	)			`[inline]`

Definition at line 886 of file HistogramSvc.h.

00887   { return bookProf(nameAndTitle, nameAndTitle, BINS(x), BINS(y));            }

P2D* HistogramSvc::createProfile2D	(	CSTR	name,
		CSTR	tit,
		DBINS(x)	,
		DBINS(y)	,
		double	upper,
		double	lower
	)			`[inline]`

Definition at line 889 of file HistogramSvc.h.

00890   {  return bookProf( name, tit, BINS(x), BINS(y), upper, lower);             }

P2D* HistogramSvc::createProfile2D	(	CSTR	name,
		CSTR	tit,
		DBINS(x)	,
		DBINS(y)	,
		double	upper,
		double	lower,
		CSTR
	)			`[inline]`

Definition at line 891 of file HistogramSvc.h.

00892   {  return bookProf( name, tit, BINS(x), BINS(y), upper, lower);             }

P2D* HistogramSvc::createProfile2D	(	CSTR	name,
		CSTR	title,
		const Edges &	x,
		const Edges &	y,
		double	upper,
		double	lower,
		CSTR
	)			`[inline]`

Definition at line 893 of file HistogramSvc.h.

00894   {  return bookProf(name, title, x, y, upper, lower);                        }

P2D* HistogramSvc::createProfile2D	(	CSTR	nameAndTitle,
		DBINS(x)	,
		DBINS(y)	,
		double	upper,
		double	lower
	)			`[inline]`

Definition at line 895 of file HistogramSvc.h.

00896   { return bookProf(nameAndTitle, nameAndTitle, BINS(x), BINS(y), upper, lower);}

P2D* HistogramSvc::createCopy	(	CSTR	full,
		const P2D &	h
	)			`[inline]`

Definition at line 898 of file HistogramSvc.h.

00899   {  return createCopy(i_splitPath(full), h);                                 }

P2D* HistogramSvc::createCopy	(	CSTR	par,
		CSTR	rel,
		const P2D &	h
	)			`[inline]`

Definition at line 900 of file HistogramSvc.h.

00901   {  return createCopy(createPath(par), rel, h);                              }

P2D* HistogramSvc::createCopy	(	STRPAIR	loc,
		const P2D &	h
	)			`[inline]`

Definition at line 902 of file HistogramSvc.h.

00903   {  return createCopy(loc.first, loc.second, h);                             }

P2D* HistogramSvc::createCopy	(	DataObject *	pPar,
		CSTR	rel,
		const P2D &	h
	)			`[inline]`

Definition at line 904 of file HistogramSvc.h.

00905   { return i_book(pPar, rel, h.title(), Gaudi::createProf2D(h));              }

virtual std::ostream& HistogramSvc::print	(	Base *	h,
		std::ostream &	s = `std::cout`
	)			const `[virtual]`

Print (ASCII) the 1D histogram into the output stream.

Implements IHistogramSvc.

virtual std::ostream& HistogramSvc::write	(	Base *	h,
		std::ostream &	s = `std::cout`
	)			const `[virtual]`

Write (ASCII) the 1D histogram table into the output stream.

Implements IHistogramSvc.

virtual int HistogramSvc::write	(	Base *	h,
		const char *	file_name
	)			const `[virtual]`

Write (ASCII) the 1D histogram table into a file.

Implements IHistogramSvc.

DataObject * HistogramSvc::createPath ( CSTR newPath ) [virtual]

Create all directories in a given full path.

Definition at line 145 of file HistogramSvc.cpp.

00145                                                   {
00146   std::string tmpPath = newPath;
00147   if (tmpPath[0] != SEPARATOR)    {
00148     tmpPath.insert(tmpPath.begin(), SEPARATOR);
00149     tmpPath.insert(tmpPath.begin(), m_rootName.begin(), m_rootName.end());
00150   }
00151   // Remove trailing "/" from newPath if it exists
00152   if (tmpPath.rfind(SEPARATOR) == tmpPath.length()-1) {
00153     tmpPath.erase(tmpPath.rfind(SEPARATOR),1);
00154   }
00155   DataObject* pObject = 0;
00156   StatusCode sc = DataSvc::findObject(tmpPath, pObject);
00157   if(sc.isSuccess()) {
00158     return pObject;
00159   }
00160   int sep = tmpPath.rfind(SEPARATOR);
00161   std::string rest(tmpPath, sep+1, tmpPath.length()-sep);
00162   std::string subPath(tmpPath, 0, sep);
00163   if(0 != sep) {
00164     createPath(subPath);
00165   }
00166   else {
00167     MsgStream log(msgSvc(), name());
00168     log << MSG::ERROR << "Unable to create the histogram path" << endmsg;
00169     return 0;
00170   }
00171   pObject = createDirectory(subPath, rest);
00172   return pObject;
00173 }

DataObject * HistogramSvc::createDirectory	(	CSTR	parentDir,
		CSTR	subDir
	)			`[virtual]`

Create a sub-directory in a directory.

Parameters:

	parentDir	name of the parent directory
	subDir	to identify the histogram object in the store

Definition at line 175 of file HistogramSvc.cpp.

00175                                                                     {
00176   DataObject*  directory = new DataObject();
00177   if (0 != directory)  {
00178     DataObject* pnode;
00179     StatusCode status = DataSvc::retrieveObject(parentDir, pnode);
00180     if(status.isSuccess()) {
00181       status = DataSvc::registerObject(pnode, subDir, directory);
00182       if (!status.isSuccess())   {
00183         MsgStream log(msgSvc(), name());
00184         log << MSG::ERROR << "Unable to create the histogram directory: "
00185                           << parentDir << "/" << subDir << endmsg;
00186         delete directory;
00187         return 0;
00188       }
00189     }
00190     else {
00191       MsgStream log(msgSvc(), name());
00192       log << MSG::ERROR << "Unable to create the histogram directory: "
00193                         << parentDir << "/" << subDir << endmsg;
00194       delete directory;
00195       return 0;
00196     }
00197   }
00198   return directory;
00199 }

void HistogramSvc::update1Ddefs ( Property & )

handler to be invoked for updating property m_defs1D

Definition at line 423 of file HistogramSvc.cpp.

00424 {
00425   // check and remove the leading '/stat/'
00426   removeLeading  ( m_defs1D , "/stat/" ) ;
00427 }

Friends And Related Function Documentation

friend class SvcFactory< HistogramSvc > [friend]

Definition at line 55 of file HistogramSvc.h.

Member Data Documentation

DBaseEntries HistogramSvc::m_input [protected]

Input streams.

Definition at line 122 of file HistogramSvc.h.

H2D* const H3D HistogramSvc::int

Definition at line 799 of file HistogramSvc.h.

H2D* const H3D int NOT_IMPLEMENTED H2D* CSTR HistogramSvc::tit

Definition at line 803 of file HistogramSvc.h.

Histo1DMap HistogramSvc::m_defs1D [private]

Definition at line 951 of file HistogramSvc.h.

std::set<std::string> HistogramSvc::m_mods1D [private]

Definition at line 954 of file HistogramSvc.h.

The documentation for this class was generated from the following files:

/afs/cern.ch/sw/Gaudi/releases/GAUDI/GAUDI_v21r8/GaudiSvc/src/HistogramSvc/HistogramSvc.h
/afs/cern.ch/sw/Gaudi/releases/GAUDI/GAUDI_v21r8/GaudiSvc/src/HistogramSvc/HistogramSvc.cpp


Public Types
typedef std::map< std::string, Gaudi::Histo1DDef >	Histo1DMap
Public Member Functions
	HistogramSvc (CSTR name, ISvcLocator *svc)
	Statndard Constructor.
virtual	~HistogramSvc ()
	Destructor.
std::pair< std::string, std::string >	i_splitPath (CSTR full)
	Split full path into its components.
StatusCode	connectInput (CSTR ident)
	Connect input histogram file to the service.
std::string	_STR (int i)
template<class T>
T *	i_book (DataObject pPar, CSTR rel, CSTR title, const std::pair< DataObject , T * > &o)
H2D *	i_project (CSTR nameAndTitle, const H3D &h, CSTR dir)
	Helper for 2D projections.
virtual StatusCode	initialize ()
	Initialise the service.
virtual StatusCode	reinitialize ()
	Initialise the service.
virtual StatusCode	finalize ()
	finalize the service
virtual AIDA::IHistogramFactory *	histogramFactory ()
	Retrieve the AIDA HistogramFactory interface.
virtual H1D *	book (CSTR par, CSTR rel, CSTR title, DBINS(x))
	Book histogram and register it with the histogram data store.
virtual H1D *	book (CSTR par, int hID, CSTR title, DBINS(x))
virtual H1D *	book (DataObject *pPar, int hID, CSTR title, DBINS(x))
virtual H1D *	book (DataObject *pPar, CSTR rel, CSTR title, DBINS(x))
virtual H1D *	book (STRPAIR loc, CSTR title, DBINS(x))
virtual H1D *	book (CSTR full, CSTR title, DBINS(x))
virtual P1D *	bookProf (CSTR par, CSTR rel, CSTR title, DBINS(x), CSTR opt)
	Book histogram and register it with the histogram data store.
virtual P1D *	bookProf (CSTR par, int hID, CSTR title, DBINS(x), CSTR opt)
virtual P1D *	bookProf (DataObject *pPar, int hID, CSTR title, DBINS(x), CSTR opt)
virtual P1D *	bookProf (STRPAIR loc, CSTR title, DBINS(x), CSTR opt)
virtual P1D *	bookProf (CSTR full, CSTR title, DBINS(x), CSTR opt)
virtual P1D *	bookProf (DataObject *pPar, CSTR rel, CSTR title, DBINS(x), CSTR opt)
virtual P1D *	bookProf (CSTR par, CSTR rel, CSTR title, DBINS(x), double upper, double lower, CSTR opt)
virtual P1D *	bookProf (CSTR par, int hID, CSTR title, DBINS(x), double upper, double lower, CSTR opt)
virtual P1D *	bookProf (DataObject *pPar, int hID, CSTR title, DBINS(x), double upper, double lower, CSTR opt)
virtual P1D *	bookProf (STRPAIR loc, CSTR title, DBINS(x), double upper, double lower, CSTR opt)
virtual P1D *	bookProf (CSTR full, CSTR title, DBINS(x), double upper, double lower, CSTR opt)
virtual P1D *	bookProf (DataObject *pPar, CSTR rel, CSTR title, DBINS(x), double upper, double lower, CSTR opt)
virtual H1D *	book (CSTR par, int hID, CSTR title, Edges e)
	Book histogram and register it with the histogram data store.
virtual H1D *	book (DataObject *pPar, int hID, CSTR title, Edges e)
virtual H1D *	book (CSTR par, CSTR rel, CSTR title, Edges e)
virtual H1D *	book (STRPAIR loc, CSTR title, Edges e)
virtual H1D *	book (CSTR full, CSTR title, Edges e)
virtual H1D *	book (DataObject *pPar, CSTR rel, CSTR title, Edges e)
virtual P1D *	bookProf (CSTR full, CSTR title, Edges e)
	Book histogram and register it with the histogram data store.
virtual P1D *	bookProf (CSTR par, CSTR rel, CSTR title, Edges e)
virtual P1D *	bookProf (CSTR par, int hID, CSTR title, Edges e)
virtual P1D *	bookProf (DataObject *pPar, int hID, CSTR title, Edges e)
virtual P1D *	bookProf (STRPAIR loc, CSTR title, Edges e)
virtual P1D *	bookProf (DataObject *pPar, CSTR rel, CSTR title, Edges e)
virtual P1D *	bookProf (CSTR full, CSTR title, Edges e, double upper, double lower)
virtual P1D *	bookProf (CSTR par, CSTR rel, CSTR title, Edges e, double upper, double lower)
virtual P1D *	bookProf (CSTR par, int hID, CSTR title, Edges e, double upper, double lower)
virtual P1D *	bookProf (DataObject *pPar, int hID, CSTR title, Edges e, double upper, double lower)
virtual P1D *	bookProf (STRPAIR loc, CSTR title, Edges e, double upper, double lower)
virtual P1D *	bookProf (DataObject *pPar, CSTR rel, CSTR title, Edges e, double upper, double lower)
virtual H2D *	book (CSTR full, CSTR title, DBINS(x), DBINS(y))
	Book histogram and register it with the histogram data store.
virtual H2D *	book (CSTR par, CSTR rel, CSTR title, DBINS(x), DBINS(y))
virtual H2D *	book (CSTR par, int hID, CSTR title, DBINS(x), DBINS(y))
virtual H2D *	book (STRPAIR loc, CSTR title, DBINS(x), DBINS(y))
virtual H2D *	book (DataObject *pPar, int hID, CSTR title, DBINS(x), DBINS(y))
virtual H2D *	book (DataObject *pPar, CSTR rel, CSTR title, DBINS(x), DBINS(y))
virtual P2D *	bookProf (CSTR full, CSTR title, DBINS(x), DBINS(y), double upper, double lower)
	Book histogram and register it with the histogram data store.
virtual P2D *	bookProf (CSTR par, CSTR rel, CSTR title, DBINS(x), DBINS(y), double upper, double lower)
virtual P2D *	bookProf (STRPAIR loc, CSTR title, DBINS(x), DBINS(y), double upper, double lower)
virtual P2D *	bookProf (CSTR par, int hID, CSTR title, DBINS(x), DBINS(y), double upper, double lower)
virtual P2D *	bookProf (DataObject *pPar, int hID, CSTR title, DBINS(x), DBINS(y), double upper, double lower)
virtual P2D *	bookProf (DataObject *pPar, CSTR rel, CSTR title, DBINS(x), DBINS(y), double upper, double lower)
virtual P2D *	bookProf (CSTR full, CSTR title, DBINS(x), DBINS(y))
virtual P2D *	bookProf (CSTR par, CSTR rel, CSTR title, DBINS(x), DBINS(y))
virtual P2D *	bookProf (STRPAIR loc, CSTR title, DBINS(x), DBINS(y))
virtual P2D *	bookProf (CSTR par, int hID, CSTR title, DBINS(x), DBINS(y))
virtual P2D *	bookProf (DataObject *pPar, int hID, CSTR title, DBINS(x), DBINS(y))
virtual P2D *	bookProf (DataObject *pPar, CSTR rel, CSTR title, DBINS(x), DBINS(y))
virtual H2D *	book (CSTR full, CSTR title, Edges x, Edges y)
	Book histogram and register it with the histogram data store.
virtual H2D *	book (CSTR par, CSTR rel, CSTR title, Edges x, Edges y)
virtual H2D *	book (CSTR par, int hID, CSTR title, Edges x, Edges y)
virtual H2D *	book (STRPAIR loc, CSTR title, Edges x, Edges y)
virtual H2D *	book (DataObject *pPar, int hID, CSTR title, Edges x, Edges y)
virtual H2D *	book (DataObject *pPar, CSTR rel, CSTR title, Edges x, Edges y)
virtual P2D *	bookProf (CSTR full, CSTR title, Edges x, Edges y)
	Book histogram and register it with the histogram data store.
virtual P2D *	bookProf (CSTR par, CSTR rel, CSTR title, Edges x, Edges y)
virtual P2D *	bookProf (CSTR par, int hID, CSTR title, Edges x, Edges y)
virtual P2D *	bookProf (DataObject *pPar, int hID, CSTR title, Edges x, Edges y)
virtual P2D *	bookProf (STRPAIR loc, CSTR title, Edges x, Edges y)
virtual P2D *	bookProf (DataObject *pPar, CSTR rel, CSTR title, Edges x, Edges y)
virtual P2D *	bookProf (CSTR full, CSTR title, Edges x, Edges y, double upper, double lower)
virtual P2D *	bookProf (CSTR par, CSTR rel, CSTR title, Edges x, Edges y, double upper, double lower)
virtual P2D *	bookProf (CSTR par, int hID, CSTR title, Edges x, Edges y, double upper, double lower)
virtual P2D *	bookProf (DataObject *pPar, int hID, CSTR title, Edges x, Edges y, double upper, double lower)
virtual P2D *	bookProf (STRPAIR loc, CSTR title, Edges x, Edges y, double upper, double lower)
virtual P2D *	bookProf (DataObject *pPar, CSTR rel, CSTR title, Edges x, Edges y, double upper, double lower)
virtual H3D *	book (CSTR full, CSTR title, DBINS(x), DBINS(y), DBINS(z))
	Book histogram and register it with the histogram data store.
virtual H3D *	book (CSTR par, CSTR rel, CSTR title, DBINS(x), DBINS(y), DBINS(z))
virtual H3D *	book (CSTR par, int hID, CSTR title, DBINS(x), DBINS(y), DBINS(z))
virtual H3D *	book (DataObject *pPar, int hID, CSTR title, DBINS(x), DBINS(y), DBINS(z))
virtual H3D *	book (STRPAIR loc, CSTR title, DBINS(x), DBINS(y), DBINS(z))
virtual H3D *	book (DataObject *pPar, CSTR rel, CSTR title, DBINS(x), DBINS(y), DBINS(z))
virtual H3D *	book (CSTR full, CSTR title, Edges x, Edges y, Edges z)
	Book histogram and register it with the histogram data store.
virtual H3D *	book (CSTR par, CSTR rel, CSTR title, Edges x, Edges y, Edges z)
virtual H3D *	book (CSTR par, int hID, CSTR title, Edges x, Edges y, Edges z)
virtual H3D *	book (DataObject *pPar, int hID, CSTR title, Edges x, Edges y, Edges z)
virtual H3D *	book (STRPAIR loc, CSTR title, Edges x, Edges y, Edges z)
virtual H3D *	book (DataObject *pPar, CSTR rel, CSTR title, Edges x, Edges y, Edges z)
virtual StatusCode	registerObject (CSTR parent, CSTR rel, Base *obj)
virtual StatusCode	registerObject (CSTR parent, int item, Base *obj)
virtual StatusCode	registerObject (Base pPar, CSTR rel, Base obj)
virtual StatusCode	registerObject (DataObject pPar, int item, Base obj)
virtual StatusCode	registerObject (Base pPar, int item, Base obj)
virtual StatusCode	registerObject (CSTR full, Base *obj)
virtual StatusCode	registerObject (DataObject pPar, CSTR rel, Base obj)
virtual StatusCode	unregisterObject (Base *obj)
virtual StatusCode	unregisterObject (Base *obj, CSTR objectPath)
virtual StatusCode	unregisterObject (Base *obj, int item)
virtual StatusCode	retrieveObject (IRegistry pReg, CSTR path, H1D &obj)
virtual StatusCode	retrieveObject (IRegistry pReg, CSTR path, P1D &obj)
virtual StatusCode	retrieveObject (IRegistry pReg, CSTR path, H2D &obj)
virtual StatusCode	retrieveObject (IRegistry pReg, CSTR path, P2D &obj)
virtual StatusCode	retrieveObject (IRegistry pReg, CSTR path, H3D &obj)
virtual StatusCode	retrieveObject (CSTR full, P1D *&obj)
virtual StatusCode	retrieveObject (CSTR full, P2D *&obj)
virtual StatusCode	retrieveObject (CSTR full, H1D *&obj)
virtual StatusCode	retrieveObject (CSTR full, H2D *&obj)
virtual StatusCode	retrieveObject (CSTR full, H3D *&obj)
virtual StatusCode	retrieveObject (CSTR parent, CSTR rel, P1D *&obj)
virtual StatusCode	retrieveObject (CSTR parent, CSTR rel, P2D *&obj)
virtual StatusCode	retrieveObject (CSTR parent, CSTR rel, H1D *&obj)
virtual StatusCode	retrieveObject (CSTR parent, CSTR rel, H2D *&obj)
virtual StatusCode	retrieveObject (CSTR parent, CSTR rel, H3D *&obj)
virtual StatusCode	retrieveObject (CSTR parent, int item, P1D *&obj)
virtual StatusCode	retrieveObject (CSTR parent, int item, P2D *&obj)
virtual StatusCode	retrieveObject (CSTR parent, int item, H1D *&obj)
virtual StatusCode	retrieveObject (CSTR parent, int item, H2D *&obj)
virtual StatusCode	retrieveObject (CSTR parent, int item, H3D *&obj)
virtual StatusCode	retrieveObject (DataObject par, CSTR item, P1D &obj)
virtual StatusCode	retrieveObject (DataObject par, CSTR item, P2D &obj)
virtual StatusCode	retrieveObject (DataObject par, CSTR item, H1D &obj)
virtual StatusCode	retrieveObject (DataObject par, CSTR item, H2D &obj)
virtual StatusCode	retrieveObject (DataObject par, CSTR item, H3D &obj)
virtual StatusCode	retrieveObject (DataObject par, int item, P1D &obj)
virtual StatusCode	retrieveObject (DataObject par, int item, P2D &obj)
virtual StatusCode	retrieveObject (DataObject par, int item, H1D &obj)
virtual StatusCode	retrieveObject (DataObject par, int item, H2D &obj)
virtual StatusCode	retrieveObject (DataObject par, int item, H3D &obj)
virtual StatusCode	retrieveObject (Base par, int item, P1D &obj)
virtual StatusCode	retrieveObject (Base par, int item, P2D &obj)
virtual StatusCode	retrieveObject (Base par, int item, H1D &obj)
virtual StatusCode	retrieveObject (Base par, int item, H2D &obj)
virtual StatusCode	retrieveObject (Base par, int item, H3D &obj)
virtual StatusCode	retrieveObject (Base par, CSTR item, P1D &obj)
virtual StatusCode	retrieveObject (Base par, CSTR item, P2D &obj)
virtual StatusCode	retrieveObject (Base par, CSTR item, H1D &obj)
virtual StatusCode	retrieveObject (Base par, CSTR item, H2D &obj)
virtual StatusCode	retrieveObject (Base par, CSTR item, H3D &obj)
virtual StatusCode	findObject (IRegistry pReg, CSTR path, P1D &obj)
virtual StatusCode	findObject (IRegistry pReg, CSTR path, P2D &obj)
virtual StatusCode	findObject (IRegistry pReg, CSTR path, H1D &obj)
virtual StatusCode	findObject (IRegistry pReg, CSTR path, H2D &obj)
virtual StatusCode	findObject (IRegistry pReg, CSTR path, H3D &obj)
virtual StatusCode	findObject (CSTR full, P1D *&obj)
virtual StatusCode	findObject (CSTR full, P2D *&obj)
virtual StatusCode	findObject (CSTR full, H1D *&obj)
virtual StatusCode	findObject (CSTR full, H2D *&obj)
virtual StatusCode	findObject (CSTR full, H3D *&obj)
virtual StatusCode	findObject (CSTR par, CSTR rel, P1D *&obj)
virtual StatusCode	findObject (CSTR par, CSTR rel, P2D *&obj)
virtual StatusCode	findObject (CSTR par, CSTR rel, H1D *&obj)
virtual StatusCode	findObject (CSTR par, CSTR rel, H2D *&obj)
virtual StatusCode	findObject (CSTR par, CSTR rel, H3D *&obj)
virtual StatusCode	findObject (CSTR par, int item, P1D *&obj)
virtual StatusCode	findObject (CSTR par, int item, P2D *&obj)
virtual StatusCode	findObject (CSTR par, int item, H1D *&obj)
virtual StatusCode	findObject (CSTR par, int item, H2D *&obj)
virtual StatusCode	findObject (CSTR par, int item, H3D *&obj)
virtual StatusCode	findObject (DataObject par, int item, P1D &obj)
virtual StatusCode	findObject (DataObject par, int item, P2D &obj)
virtual StatusCode	findObject (DataObject par, int item, H1D &obj)
virtual StatusCode	findObject (DataObject par, int item, H2D &obj)
virtual StatusCode	findObject (DataObject par, int item, H3D &obj)
virtual StatusCode	findObject (DataObject par, CSTR item, P1D &obj)
virtual StatusCode	findObject (DataObject par, CSTR item, P2D &obj)
virtual StatusCode	findObject (DataObject par, CSTR item, H1D &obj)
virtual StatusCode	findObject (DataObject par, CSTR item, H2D &obj)
virtual StatusCode	findObject (DataObject par, CSTR item, H3D &obj)
virtual StatusCode	findObject (Base par, int item, P1D &obj)
virtual StatusCode	findObject (Base par, int item, P2D &obj)
virtual StatusCode	findObject (Base par, int item, H1D &obj)
virtual StatusCode	findObject (Base par, int item, H2D &obj)
virtual StatusCode	findObject (Base par, int item, H3D &obj)
virtual StatusCode	findObject (Base par, CSTR item, P1D &obj)
virtual StatusCode	findObject (Base par, CSTR item, P2D &obj)
virtual StatusCode	findObject (Base par, CSTR item, H1D &obj)
virtual StatusCode	findObject (Base par, CSTR item, H2D &obj)
virtual StatusCode	findObject (Base par, CSTR item, H3D &obj)
virtual H1D *	projectionX (CSTR name, const H2D &h)
virtual H1D *	projectionY (CSTR name, const H2D &h)
virtual H1D *	sliceX (CSTR name, const H2D &h, int indexY)
virtual H1D *	sliceY (CSTR name, const H2D &h, int indexX)
virtual H1D *	sliceX (CSTR name, const H2D &h, int indexY1, int indexY2)
virtual H1D *	sliceY (CSTR name, const H2D &h, int indexX1, int indexX2)
bool	destroy (IBaseHistogram *hist)
H1D *	add (CSTR nameAndTitle, const H1D &a, const H1D &b)
H1D *	subtract (CSTR nameAndTitle, const H1D &a, const H1D &b)
H1D *	multiply (CSTR nameAndTitle, const H1D &a, const H1D &b)
H1D *	divide (CSTR nameAndTitle, const H1D &a, const H1D &b)
H2D *	add (CSTR nameAndTitle, const H2D &a, const H2D &b)
H2D *	subtract (CSTR nameAndTitle, const H2D &a, const H2D &b)
H2D *	multiply (CSTR nameAndTitle, const H2D &a, const H2D &b)
H2D *	divide (CSTR nameAndTitle, const H2D &a, const H2D &b)
H3D *	add (CSTR nameAndTitle, const H3D &a, const H3D &b)
H3D *	subtract (CSTR nameAndTitle, const H3D &a, const H3D &b)
H3D *	multiply (CSTR nameAndTitle, const H3D &a, const H3D &b)
H3D *	divide (CSTR nameAndTitle, const H3D &a, const H3D &b)
H2D *	projectionXY (CSTR nameAndTitle, const H3D &h)
H2D *	projectionXZ (CSTR nameAndTitle, const H3D &h)
H2D *	projectionYZ (CSTR nameAndTitle, const H3D &h)
H2D *	sliceXY (CSTR, const H3D &, int, int) NOT_IMPLEMENTED H2D *sliceXZ(CSTR
H2D const H3D int NOT_IMPLEMENTED H2D	sliceYZ (CSTR, const H3D &, int, int) NOT_IMPLEMENTEDH1D *createHistogram1D(CSTR name
H2D const H3D int NOT_IMPLEMENTED H2D CSTR	DBINS (x))
H1D *	createHistogram1D (CSTR name, CSTR tit, DBINS(x), CSTR)
H1D *	createHistogram1D (CSTR name, CSTR title, const Edges &x, CSTR)
H1D *	createHistogram1D (CSTR nameAndTitle, DBINS(x))
H1D *	createCopy (CSTR full, const H1D &h)
H1D *	createCopy (CSTR par, CSTR rel, const H1D &h)
H1D *	createCopy (STRPAIR loc, const H1D &h)
H1D *	createCopy (DataObject *pPar, CSTR rel, const H1D &h)
H2D *	createHistogram2D (CSTR name, CSTR tit, DBINS(x), DBINS(y))
H2D *	createHistogram2D (CSTR name, CSTR tit, DBINS(x), DBINS(y), CSTR)
H2D *	createHistogram2D (CSTR name, CSTR title, const Edges &x, const Edges &y, CSTR)
H2D *	createHistogram2D (CSTR nameAndTitle, DBINS(x), DBINS(y))
H2D *	createCopy (CSTR full, const H2D &h)
H2D *	createCopy (CSTR par, CSTR rel, const H2D &h)
H2D *	createCopy (STRPAIR loc, const H2D &h)
H2D *	createCopy (DataObject *pPar, CSTR rel, const H2D &h)
H3D *	createHistogram3D (CSTR name, CSTR tit, DBINS(x), DBINS(y), DBINS(z))
H3D *	createHistogram3D (CSTR name, CSTR tit, DBINS(x), DBINS(y), DBINS(z), CSTR)
H3D *	createHistogram3D (CSTR name, CSTR title, const Edges &x, const Edges &y, const Edges &z, CSTR)
H3D *	createHistogram3D (CSTR nameAndTitle, DBINS(x), DBINS(y), DBINS(z))
H3D *	createCopy (CSTR full, const H3D &h)
H3D *	createCopy (CSTR par, CSTR rel, const H3D &h)
H3D *	createCopy (STRPAIR loc, const H3D &h)
H3D *	createCopy (DataObject *pPar, CSTR rel, const H3D &h)
P1D *	createProfile1D (CSTR name, CSTR tit, DBINS(x), CSTR opt)
P1D *	createProfile1D (CSTR name, CSTR tit, DBINS(x), double upper, double lower, CSTR opt)
P1D *	createProfile1D (CSTR name, CSTR title, const Edges &x, CSTR)
P1D *	createProfile1D (CSTR name, CSTR title, const Edges &x, double upper, double lower, CSTR)
P1D *	createProfile1D (CSTR nametit, DBINS(x))
P1D *	createProfile1D (CSTR nametit, DBINS(x), double upper, double lower)
P1D *	createCopy (CSTR full, const P1D &h)
P1D *	createCopy (CSTR par, CSTR rel, const P1D &h)
P1D *	createCopy (STRPAIR loc, const P1D &h)
P1D *	createCopy (DataObject *pPar, CSTR rel, const P1D &h)
P2D *	createProfile2D (CSTR name, CSTR tit, DBINS(x), DBINS(y))
P2D *	createProfile2D (CSTR name, CSTR tit, DBINS(x), DBINS(y), CSTR)
P2D *	createProfile2D (CSTR name, CSTR title, const Edges &x, const Edges &y, CSTR)
P2D *	createProfile2D (CSTR nameAndTitle, DBINS(x), DBINS(y))
P2D *	createProfile2D (CSTR name, CSTR tit, DBINS(x), DBINS(y), double upper, double lower)
P2D *	createProfile2D (CSTR name, CSTR tit, DBINS(x), DBINS(y), double upper, double lower, CSTR)
P2D *	createProfile2D (CSTR name, CSTR title, const Edges &x, const Edges &y, double upper, double lower, CSTR)
P2D *	createProfile2D (CSTR nameAndTitle, DBINS(x), DBINS(y), double upper, double lower)
P2D *	createCopy (CSTR full, const P2D &h)
P2D *	createCopy (CSTR par, CSTR rel, const P2D &h)
P2D *	createCopy (STRPAIR loc, const P2D &h)
P2D *	createCopy (DataObject *pPar, CSTR rel, const P2D &h)
virtual std::ostream &	print (Base *h, std::ostream &s=std::cout) const
	Print (ASCII) the 1D histogram into the output stream.
virtual std::ostream &	write (Base *h, std::ostream &s=std::cout) const
	Write (ASCII) the 1D histogram table into the output stream.
virtual int	write (Base h, const char file_name) const
	Write (ASCII) the 1D histogram table into a file.
virtual DataObject *	createPath (CSTR newPath)
	Create all directories in a given full path.
virtual DataObject *	createDirectory (CSTR parentDir, CSTR subDir)
	Create a sub-directory in a directory.
void	update1Ddefs (Property &)
	handler to be invoked for updating property m_defs1D
Static Public Member Functions
template<class T>
static DataObject *	__cast (T *p)
Public Attributes
H2D *const H3D	int
H2D const H3D int NOT_IMPLEMENTED H2D CSTR	tit
Protected Types
typedef const std::string &	CSTR
typedef std::vector< double >	Edges
typedef std::vector< std::string >	DBaseEntries
typedef AIDA::IHistogram1D	H1D
typedef AIDA::IHistogram2D	H2D
typedef AIDA::IHistogram3D	H3D
typedef AIDA::IProfile1D	P1D
typedef AIDA::IProfile2D	P2D
typedef AIDA::IBaseHistogram	Base
Protected Attributes
DBaseEntries	m_input
	Input streams.
Private Types
typedef const std::pair < std::string, std::string > &	STRPAIR
Private Member Functions
void	not_implemented () const
Private Attributes
Histo1DMap	m_defs1D
std::set< std::string >	m_mods1D
Friends
class	SvcFactory< HistogramSvc >
Classes
struct	Helper

Gaudi Framework, version v21r8

HistogramSvc Class Reference

Public Types

Public Member Functions

Static Public Member Functions

Public Attributes

Protected Types

Protected Attributes

Private Types

Private Member Functions

Private Attributes

Friends

Classes

Detailed Description

Member Typedef Documentation

Constructor & Destructor Documentation

Member Function Documentation

Friends And Related Function Documentation

Member Data Documentation
